LC-60LE635E/636E/638E (1st Edition)
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
22 LX-BZA401WJN1 AC J Screw
23 LX-NZA049WJFN AC J Screw (except LC-60LE636E)
24 NSFTZA459WJF7 AC N J Tray Shaft
25 GCOVHA137WJSA AB J Vesa Cover
26 GCOVAD981WJ2A AH N J AC Cord Cover
27 GCOVAE131WJ2A N P Bottom Cover
28 TLABNC117WJZZ P Model Label
29 PMLT-A676WJZZ P Gasket (HDMI)
30 PSHEPB131WJKZ P ICON ILLUMI DIF
31 PSLDMB651WJZZ - P Shield
32 LHLDWA303WJKA AE J Cable Clamp
33 PSPAGA963WJZZ - P PC Sheet
!
34 QACCKA055WJPZ AQ J AC Cord (except LC-60LE636K)
!
34 QACCBA106WJPZ P AC Cord (for LC-60LE636K)
35 PSPAKA486WJKZ AD J Spacer
36 QCNW-L610WJQZ AL J Connecting Cord (CI)
37 QCNW-L613WJQZ AH J Connecting Cord (SP)
38 PSPANA044WJKZ AB N J Spacer
39 QCNW-L938WJQZ N P Connecting Cord (RC)
40 RSP-ZA538WJQZ N P Speaker L
41 RSP-ZA539WJQZ N P Speaker R
42 XBPS830P06WS0 AA J Screw
43 XEBS830P08000 AA J Screw
44 XEBS830P12000 AA J Screw
45 PSPAP0463TPZZ N P -
46 PSPAZC554WJKZ AD N J 25*25*3.0t_TCON
47 PSPAZC690WJZZ P Spacer
48 TLABZD035WJZZ N P Energy Label (except Russia)
49 PSPAZC691WJZZ AE J Spacer
50 PSPAZC702WJKZ AQ J Spacer
51 PSPAZC777WJZZ N P Spacer
52 PZETKA595WJKZ N P AC Cord Barrier
53 PZETKA638WJKZ - P FFC BAR SHT T
54 PZETKA639WJKZ - P FFC BAR SHT B
55 QEARZ0057CEFW AB J Spring(Tuner)
56 RCORFA020WJZZ AN - J Core
57 RCORFA061WJZZ AG J Ferrite core
58 HiNDPE122WJSB N P P_INDICATOR/BTM (for U.K.)
59 TLABZC453WJZZ P Panel Label
[6] SUPPLIED ACCESSORIES/PACKING PARTS
X1 CANGKD276WJ05 N P Stand Support Ass'y
X2 CDAi-A778WJ22 N P Stand Base Ass'y
X3 CSAKKA011WJ03 N P Stand Screw Ass'y
X4 LHLDWA303WJKA P Cable Clamp
X5 RRMCGA903WJSA P Remote Control (LC-60LE635E/636E)
X5 RRMCGA984WJSA P Remote Control (LC-60LE638E)
X6 TCAUZA477WJZZ N P Safety Sheet
X7 TCAUZA446WJZZ P Weee Sheet (except Russia)
X8 TiNS-F305WJZZ N P Set Up Guide
X9 TCAUZA458WJN1 P Wifi Sheet
X10 UBATAA011WJZZ P AAA size Battery
X11 Ki-OUA003WJQZ P USB Dongle
X12 UiMCUA006WJQZ2 N P USB Memory
X13 TGAN-A801WJN1 P Guarantee Card (for U.K.)
X14 TGAN-A802WJN1 P Guarantee/AQUOS (for U.K.)
X15 TCAUZA478WJZZ P Gost Sheet (for Russia.)
X16 TGAN-B651WJZZ P Guarantee Sheet (for Russia.)
X17 LHLDWA303WJKA P Cable Clamp
S1 SPAKCG502WJZZ - N - Packing Case (Main)
S2 SPAKCG379WJZZ - - P-Case Bottom
S4 SPAKXD490WJZZ - N - Packing Add (Top)
S5 SPAKXD491WJZZ - N - Packing FOAM (Bottom)
S7 SPAKPB723WJ2Z - - Stand Mat (Support)
S8 SPAKPB722WJ2Z - - Miror Mat (Base)
S8 SSAKAA111WJZZ - - Polyethylene Bag
S9 SPAKPB750WJZZ - - SACK
S10 SSAKKA011WJ2Z - - Polyethylene Bag
S11 TLABM5584BMZZ - - Case Label
S12 TLABK0023TAZZ - - Label For R/C (except LC-60LE636E)
S13 TLABZC826WJZZ P Bar Code Label
[7] SERVICE JIGS (USE FOR SERVICING)
N QCNW-C222WJQZ J Main Unit to LCD Control to LCD Panel, x2
N QCNW-L795WJQZ J Main Unit to Power Unit (PD)
N QCNW-L796WJQZ J Main Unit to ICON Unit (CI)
N QCNW-K595WJQZ J Main Unit to Speaker (SP)
N QCNW-G405WJQZ J Main Unit to LCD Control Unit (PL)
N QCNW-F676WJQZ J Main Unit to LCD Control Unit (LW)
[5] CABINET PARTS
To Next Page
