Sharp LC-65LE643U FPTW - Chapter 2 Product Specifications; TFT LCD Panel Characteristics; Input and Output Connectors

CONFIDENTIAL – DO NOT COPY
Page 2-1
File No. SG-0000239
Chapter 2 Specification
1. TFT LCD CHARACTERISTICS
TFT-LCD SKD model T650HVN05.5
Item Specification
Panel T650HVN05.5
Display Pixels 1428.48 (H) x 803.52 (V)
Active Screen Size 65.00 inch
Color Depth 10 bit, 1.07B
Pixel Pitch 0.744 mm
Luminance of White (cd/m
2
) 350 (Typical); 280(Min) (cd/m
2
)
Contrast Ratio 4000 :1 (TYP)
x 0.28
White
y 0.29
x
0.6454
Red
y
0.3327
x
0.2880
Green
y 0.6524
x
0.1519
Color
Coordinates
Typical
±0.030
Blue
y
0.0424
2. Input Connectors
USBX1, HDMIX3
with HDCP(CEC, 1 ARC, 1 MHL), RCAX1 (Component), 1x
Composite Video and Stereo Audio(Shared to Component),
Tuner, 1x Stereo RCA
Jack(R/L) (with Component-RCA & Composite-RCA)
3. Output Connectors
SPDIF Out (Optical Audio),
1x Stereo RCA (R/L)
4. Power Supply
Input voltage: 120Vac, 60Hz
Input current: 2.2 A
Power consumption (w/set): 240W (max), with audio full output
Standby (w/set): <1.0W (at 120 Vac input)
5.Speaker
Output 10W(max) X 2(6Ω)
