Sharp LC-65LE643U FPTW User Manual

CONFIDENTIAL – DO NOT COPY
Page 13-1
File No. SG-0000239
Chapter 13 Spare Parts List
PART NO DESCRIPTION LOC QTY REMARK
9LE018467510083
POLYSWITCH 0.75A 8V SMD (1206L075THYR) HF
FU5
1
9LE028024000313
X'TAL 24MHZ 49S 20PF 30PPM -40~85'C LF
Y1,Y2
2
9LE030064000070
OPTO CONN. Transmitter (JST1221) L-F
PA1
1
9LE032040000470
POWER CORD 2P POLA. 1500mm 7A
UL/CSA(SP-12/IS-08A) N.M(SH)
1
9LE03351006AF51
SPK 10W 6ohm (1150*650mm) +spong FPTW for
LC-65 & LC55
1
9LE039050034293
DUAL SURFACE DIODE BAV70-7-F SMD (SOT-23)
L-F
DA1,DA5,DV1
3
9LE039060050293
Schottky Diode 0.2A 30V BAT54C-7-F SOT-23 HF
DV2
1
9LE039060110273
Schottky Diode 0.2A 30V BAT54C SOT-23 HF
DV2
1
9LE0430604260C1
IC STEP-DOWN CONV 3A 23V FR9889SPCTR SOP-
8
LF
UP17
1
9LE041050005638
TR NPN 0.2A 40V LMBT3904LT1G SOT-23 HF
QA1,QA3,QA4,QH8,QH9,QI2,
QL1,QM3,QP10
9
9LE042020073636
MOSFET P-CH 9.5A 30V SSG4835P SOP 8PIN LF
UL2
1
9LE042020092643
MOSFET P-CH 3.2A 30V ME2303-G SOT-23 HF
QP4
1
9LE043000016609
IC CMOS LOGIC 74HC4052PW TSSOP 16PIN LF
UH4
1
9LE043000047015
IC CMOS CD74HC4094M96 SOIC-16 LF
U2,U3
2
9LE043030149045
IC SERIAL FLASH 8M MX25L8006EM2I-12G SOP-8
LF
UM2
1
9LE043030163045
IC SERIAL FLASH 32M MX25L3206EM2I-12G SOP-8
LF
US4
1
9LE043050318985
IC MEMC MST7438BB EPLQFP-128 HF
UM1
1
9LE043060270079
IC LDO 1A ADJ AP1117EG-13 SOT223-3L 3PIN HF
UP3,UP4
2
9LE043060437039
IC STEP-DOWN CONV 1.5A 6V LA8013ACD
SOT-23-5 LF
UP15,UP16,UP18,UP19
4
9LE043060440015
IC STEP-DOWN CONV 5A 28V TPS54531DDAR
SOIC-8 PowerPAD HF
UP2
1
9LE043070865615
IC AUDIO OP DRV632PWR TSSOP-14 HF
UA2
1
9LE043070921721
IC AUDIO DSP NPCA110DA0YX QFN-32 LF
UW1
1
9LE043070942715
IC AUDIO POWER AMP 20W TAS5707LPHPR
HTQFP-48 HF
UA1
1
9LE043070956079
IC RESET 4.38V APX810-44SAG-7 SOT-23 HF
US1
1
9LE043071043079
IC POWER SWITCH 2.1A AP2191WG-7 SOT-23-5 HF
UH3
1
9LE043140020999
IC SCALER MSD8220LBP W/O DDP EPLQFP-156 HF
U1
1
9LE045120000406
WAFER 2.0mm 4P 180' DIP KINK (M24264) HF J2,J3
2
9LE045120000466
WAFER 2.0mm 4P 90' DIP KINK (M24264R) HF JI3
1
9LE045120000666
WAFER 2.0mm 6P 90' DIP KINK (M24266R) HF J13
1
9LE045120001066
WAFER 2.0mm 10P 90' DIP KINK (M242610R) HF JP1
1
9LE045125000446
WAFER 2.5mm 4P 90' DIP KINK (M241854R) L-F JA1
1
