LC-70LE632U/633U
i
LC70LE632U
Service Manual
OUTLINE, MODIFIED PARTS AND MAJOR SERVICE PARTS
OUTLINE
This model is based on the LC-70LE732U and partially modified.
For the contents not covered in this Service Manual, accordingly, please refer to the LC-70LE732U (S31o870LE732U) Service Manual.
The following model label corresponds to this service manual.
MODIFIED PARTS
Ref. No. Description LC-70LE732U
(S31O870LE732U)
LC-70LE632U
LC-70LE633U
(S91T870LE632U)
Inter-
change-
ability
Note
PRINTED WIRING BOARD ASSEMBLIES
N MAIN Unit DKEYMF733FM19 DKEYMF733FMN8 D Chanded
N R/C OPC Unit DUNTKF494FM01 ← - No Changed
N ICON Unit DUNTKF770FM02 ← - No Changed
N KEY Unit DUNTKF800FM51 DUNTKF800FM50 D Changed
N WiFi Unit RUNTKA810WJQZ ← - No Changed
N POWER/DRIVE Unit (LC-70LE632U) RUNTKA857WJQZ ← - No Changed
N POWER Unit (LC-70LE633U) - RDENCA442WJQZ - Add
N LED DRIVER Unit (LC-70LE633U) - RUNTKA842WJZZ - Add
N LCD Control Unit DUNTKF778FM04 DUNTKF778FM13 D Chanded
LCD Panel Module
N 70" LCD Panel Module Unit(LC-70LE632U) R1LK695D3GW30Z R1LK695D3GW50Z D Chanded
N 70" LCD Panel Module Unit(LC-70LE633U) R1LK695D3GW30Z R1LK695D3GW60Z D Chanded
MAIN Unit
C9665 Capacitor 0.10 10V Ceramic - VCKYCZ1AB104KY - Add
IC2005 IC BR24L02F-WE2 VHiR24002AS-1Y VHiBR24L02F1EY D Chanded
IC3501 IC K4B1G1646G-BCH9 RH-iXD226WJQZQ RH-iXD266WJQZQ D Chanded
IC3502 IC K4B1G1646G-BCH9 RH-iXD226WJQZQ RH-iXD266WJQZQ D Chanded
IC3503 IC K4B1G1646G-BCH9 RH-iXD226WJQZQ RH-iXD266WJQZQ D Chanded
IC9611 IC 74HC2G66DP,125 - VHiHC2G66DP-1Y - Add
J9501 Jack QJAKZA105WJQZY QJAKZA105WJQZQ D Chanded
L1501 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L1502 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L1503 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L1504 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L2607 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L2608 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L2609 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L2610 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L9501 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L9502 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
L9503 Coil RCiLFA228WJZZY RCiLFA294WJZZY D Chanded
R8416 Resistor 0 1/16W Metal Oxide - VRS-CZ1JF000JY - Add
R8417 Resistor 0 1/16W Metal Oxide - VRS-CZ1JF000JY - Add
CABINET AND MECHANICAL PARTS
Please refer to a Parts Guide.
SUPPLIED ACCESSORIES/PACKING PARTS (NOT REPLACEMENT ITEM)
Please refer to a Parts Guide.
SERVICE JIG (USE FOR SERVICING)
Please refer to a Parts Guide.
Interchangeability
Completely interchangeableA:
=
NEWOLD
Interchangeable from
OLD to NEW
B:
NEWOLD
Interchangeable from
NEW to OLD
C:
NEW OLD
Not interchangeableD:
X
OLDNEW
