PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-70LE632U/633U
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
[2] LCD PANEL MODULE UNIT
[3] DKEYMF733FMN8 (MAIN Unit)
[4] CABINET PARTS
[5] SUPPLIED ACCESSORIES/
PACKING PARTS
[6] SERVICE JIGS (USE FOR
SERVICING)
CONTENTS
No. S91T870LE632U
LCD COLOR TELEVISION
LC-70LE632U
LC-70LE633U
MODELS
