Sharp LC-70LE632U - Major Service Parts

LC-70LE632U/633U
ii
MAJOR SERVICE PARTS
PWB Unit
NOTE: *1 Replace MAIN PWB Unit (DKEYMF733FM26) in case of IC8401, IC3303 or IC8455 failure.
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
Ref. No. Parts No. Description
N DKEYMF733FMN8 MAIN Unit
N DUNTKF494FM01 R/C OPC Unit
N DUNTKF770FM02 ICON Unit
N DUNTKF800FM50 KEY Unit
N RUNTKA810WJQZ WiFi Unit
N RUNTKA857WJQZ POWER/DRIVE Unit (LC-70LE632U)
N RDENCA442WJQZ POWER Unit (LC-70LE633U)
N RUNTKA842WJZZ LED DRIVER Unit (LC-70LE633U)
N DUNTKF778FM13 LCD Control Unit
Ref. No. Parts No. Description
N R1LK695D3GW50Z 70" LCD Panel Module Unit(LC-70LE632U)
N R1LK695D3GW60Z 70" LCD Panel Module Unit(LC-70LE633U)
Ref. No. Parts No. Description Q'ty
IC2001 RH-iXD241WJNBQ IC R5F21368CNFP (Monitor Microcomputer) 1
Ref. No. Parts No. Description Q'ty
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit 2
N QCNW-F676WJQZ Connecting Cord L=1000mm 41pins, Main to LCD Control Unit (LW) 1
N QCNW-L795WJQZ Connecting Cord L=1000mm 24pins, Main to POWER Unit (PD) 1
N QCNW-G405WJQZ Connecting Cord L=1000mm 4pins, Power to LCD Control Unit (PL) 1
