Sharp LC-70LE740E User Manual

LC-60/70LE740E/RU,741E/S,743E,60LE840E/RU,841E/S,843E,80LE645E/RU,646E/S,648E (1st Edition)
6
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[8] CABINET AND MECHANICAL PARTS (LC-70LE740E,RU/741E,S,743E)
1 CCABAC869WJ12 N P Front Cabinet Ass'y
1-1 GCABAC869WJ1A P Front Cabinet
1-2 GCOVAD966WJ1A P R/C OPC Cover
1-3 HDECQB633WJ3B N P Front Decoration
1-4 LHLDWA124WJKZ AC J WireHolder, x2
1-5 LHLDWA175WJUZ AC J WireHolder, x3
1-6 PSHEPB131WJKZ P ICON Decoration
1-7 PSHEZA346WJZZ P Protect Sheet
2 CCABBC049WJ11 N P Rear Cabinet Ass'y (for LC-70LE740E,RU/743E)
2 CCABBC049WJ12 N P Rear Cabinet Ass'y (for LC-70LE741E,S)
2-1 GCABBC049WJ1A N P Rear Cabinet
2-2 HiNDPE032WJSB P Indicator (Bottom) (for LC-70LE740E,RU/743E)
2-2 HiNDPE122WJSB P Indicator (Bottom) (for LC-70LE741E,S)
2-3 HiNDPE035WJSB P Indicator (Back)
2-4 HiNDPE117WJSB P Indicator (Side)
3 CANGKD483WJ31 N P Vese Angke Ass'y, x4
3-1 LANGKD483WJ3W N P Vese Angke
3-2 NSFTZA460WJFN BC J Vese Shaft
4 GCOVAE163WJ3A P AC Code Cover
5 GCOVAE335WJ3A N P Bottom Cover
6 GCOVAE431WJ3A N P KEY Cover
7 JBTN-A912WJ3A P KEY Button
8 LANGKD485WJ3W N P Stand Angle, x2
9 LANGKD561WJ3W N P Angle (TRM-BTM) (for LC-70LE740E,RU/743E)
9 LANGKD562WJ3W N P Angle (TRM-BTM) (for LC-70LE741E,S)
10 LANGTA593WJ1W N P Angle (TOP-L/R), x2
11 LANGTA594WJ1W N P Angle TOP/Center)
12 LANGTA596WJ1W N P Angle (SIDE), x2
13 LANGTA598WJ1W N P Angle (BOTTOM-L/R), x2
14 LANGTA599WJ1W N P Angle (BOTTOM/Center)
15 LHLDWA176WJUZ AC J WireHolder, x2
16 LHLDWA294WJUZ AC J WireHolder
17 LHLDWA303WJKA AE J AC Cord Band
18 LHLDWA347WJKZ P
WireHolder, x7
19 LX-BZA207WJF7 AA J Screw, x24
20 LX-EZA069WJF7 AB J Screw, x2
21 LX-NZA049WJFN AC J Screw (for LC-70LE740E,RU/743E)
22 PMLT-A676WJZZ P Gasket (HDMI)
23 PMLT-A690WJQZ N P Gasket, x2 (MAIN)
24 PMLT-A691WJQZ N P Gasket, x2 (MAIN)
25 PSLDMB796WJ3W N P Main PWB Shield
26 PSPAZC805WJKZ N P Spacer
27 PSPAZC823WJ3Z P Spacer, x2
28 PSPAZC887WJKZ N P Spacer
!
29 QACCKA055WJPZ AQ J AC Cord (except LC-70LE741E)
!
29 QACCBA106WJPZ AS J AC Cord (for LC-70LE741E)
30 QCNW-M030WJQZ AL N J Connecting Cord (SP)
31 QCNW-M034WJQZ N P Connecting Cord (CI)
32 QCNW-M167WJQZ N P Connecting Cord (RC)
33 QCNW-M168WJQZ N P Connecting Cord (LW)
34 QCNW-M725WJQZ N P Connecting Cord (PD)
35 QCNW-M787WJQZ N P Connecting Cord (PL)
36 QCNWN2731TPZZ AF J FFC, x2
37 QEARZ0057CEFW AB J Spring
38 RCORF0103CEZZ AK J Ferrite Core
39 RSP-ZA576WJZZ AT N J Speaker (L)
40 RSP-ZA577WJZZ AT N J Speaker (R)
41 TLABNC117WJZZ P Model Label
42 TLABZC453WJZZ P Panel Label
43 TLABZD131WJZZ N P Energy Label (except LC-70LE740RU)
44 XBPS830P06WS0 AA J Screw, x49
45 XEBS830P08000 AA J Screw, x3
46 XEBS830P12000 AA J Screw, x10

Sharp LC-70LE740E Specifications

General

Display diagonal	70 \
Display brightness	- cd/m²
Native refresh rate	100 Hz
Supported video modes	1080p
Viewing angle, vertical	176 °
Display diagonal (metric)	177 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Dynamic contrast ratio marketing name	Mega Contrast
3D	Yes
Volume control	Digital
Headphone connectivity	3.5 mm
Annual energy consumption	197 kWh
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T
Audio decoders	Dolby Digital, Dolby Digital Surround EX, Dolby Virtual Speaker
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
HDCP	-
HDMI version	1.4
Composite video in	0
HDMI ports quantity	4
USB 2.0 ports quantity	1
Compatible memory cards	SD
Audio formats supported	AAC
Video formats supported	DIVX, H.264, MPEG4
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.1 W
Power consumption (typical)	135 W

Weight and Dimensions

Depth (with stand)	333 mm
Height (with stand)	1008 mm
Depth (without stand)	89 mm
Width (without stand)	1613 mm
Height (without stand)	975 mm
Weight (without stand)	40500 g
