Sharp LC-70LE740E - Chapter 4 Major Parts Removal; Location of Heat Measure Sheet

LC-60/70LE740E/RU,741E/S,743E,60LE840E/RU,841E/S,843E,80LE645E/RU,646E/S,648E (1st Edition)
4 – 1
LC60LE740E
ServiceManual

CHAPTER 4. REMOVING OF MAJOR PARTS
[1] The location putting on the heat measure sheet
1. MAIN PWB Unit
• LC-60/70LE740E/RU,741E/S,743E,LC-60LE840E/RU,841E/S,843E
• LC-80LE645E/RU,646E/S,648E
PSPAZC805W JKZ
(7) Stick***
PSPAZC871WJKZ
COOLING SHE ET
for Main(25x25 t11)
