OUTLINE
MAJOR SERVICE PARTS
PWB Unit
• (LC-60/70LE740E/RU,741E/S,743E)
NOTE: (*1) Replace MAIN Unit (DKEYDF733FM**) in case of IC8401 or IC3303 failure.
• (LC-60LE840E/RU,841E/S,843E)
• (LC-80LE645E/RU,646E/S,648E)
NOTE: (*1) Replace MAIN Unit (DKEYDF733FM**) in case of IC8401 or IC3303 failure.
OTHER Unit
Ref No. Parts No. Description
N DKEYDF733FM65 MAIN Unit (LC-60/70LE740E,RU)
N DKEYDF733FM66 MAIN Unit (LC-60/70LE741E,S)
N DKEYDF733FM68 MAIN Unit (LC-60/70LE743E)
N DUNTKF494FM02 R/C OPC Unit
N DUNTKF770FM51 ICON Unit
N DUNTKF800FM52 KEY Unit
N DUNTKG031FM51 LCD control Unit (LC-60LE740E/RU,741E/S,743E)
N DUNTKG031FM52 LCD control Unit (LC-70LE740E/RU,741E/S,743E)
N RUNTKA819WJQZ 3D-IR Transmitter Unit
N RUNTKA932WJQZ POWER Unit (LC-60LE740E,RU/741E,S/743E)
N RUNTKA933WJQZ POWER Unit (LC-70LE740E,RU/741E,S/743E)
Ref
No.
PARTS CODE DESCRIPTION
N DKEYDF733FM69 MAIN Unit (LC-60LE840E/RU)
N DKEYDF733FM70 MAIN Unit (LC-60LE841E/S)
N DKEYDF733FM71 MAIN Unit (LC-60LE843E)
N DUNTKG015FM51 R/C OPC Unit
N DUNTKG014FM51 ICON Unit
N DUNTKF800FM52 KEY Unit
N DUNTKG017FM51 3D-IR Transmitter Unit
N DUNTKF906FM56 LCD control Unit
N RUNTKA946WJQZ POWER/LED Driver Unit
N RUNTKA966WJZZ S-LED Unit (A)
N RUNTKA967WJZZ S-LED Unit (B)
Ref No. Parts No. Description
N DKEYDF733FM62 MAIN Unit (LC-80LE645E/RU)
N DKEYDF733FM63 MAIN Unit (LC-80LE646E/S)
N DKEYDF733FM64 MAIN Unit (LC-80LE648E)
N DUNTKF494FM02 R/C OPC Unit
N DUNTKF770FM53 ICON Unit
N DUNTKF800FM52 KEY Unit
N RUNTKA903WJQZ POWER Unit
N DUNTKF778FM12 LCD Control Unit
Ref
No.
PARTS CODE DESCRIPTION
N R1LK600D3GV00T 60" LCD Panel Module (LK600D3GV00T) (LC-60LE740E/RU,741E/S,743E)
N R1LK695D3GW80F 70" LCD Panel Module (LK695D3GW80F) (LC-70LE740E/RU,741E/S,743E)
N CLCDTA257WE01 60" LCD Panel Module Unit (LC-60LE840E/RU,841E/S,843E)
N R1LK600D3HB80D 60" LCD Panel (LK600D3HB80D) (LC-60LE840E/RU,841E/S,843E)
N R1LK800D3GW10V 80" LCD Panel Module Unit (LK800D3GW10V) (LC-80LE645E/RU,646E/S,648E)
