PART
DELIVERY
DESCRIPTION
[9] CABINET AND MECHANICAL PARTS (LC-60LE840E/RU,841E/S,843E)
1 CANGKD512WJ31 N P Center Angle Ass'y, x2
1-1 LANGKD512WJ3W N P Center Angle
1-2 LHLDWA175WJUZ AC J WireHolder
1-3 NSFTZA546WJFN N P Vesa Boss, x2
2 CCOVAE387WJ31 N P Decoration Ass'y
2-1 GCOVAE387WJ3A N P Decoration Cover
2-2 GCOVAE310WJ3A N P 3D-IR Cover
2-3 GCOVAE311WJ3A N P Center ICON Cover
2-4 HDECQB692WJ3A N P LED Decoration
2-5 LHLDWA151WJKZ AB J WireHolder
3 CCOVAE396WJ31 N P Bottom Cover Ass'y
3-1 GCOVAE396WJ3A N P Bottom Cover
3-2 PSPAHC565WJZZ P Himeron, x2
4 GCABBC095WJ3A P Rear Cabinet
5 GCOVAE163WJ3A P AC Cord Cover
6 HiNDPE035WJSB P Indicator (Back)
7 HiNDPE630WJSA N P Operation Label
8 HiNDPE639WJSA N P Eco SW Label
9 HiNDPE640WJSA N P Indicator (Side)
10 HiNDPE641WJSA P Indicator (Bottom) (except LC-60LE841E/S)
10 HiNDPE642WJSA P Indicator (Bottom) (for LC-60LE841E/S)
11 JBTN-A958WJ3A P KEY Button
12 LANGKD148WJFW P Angle (TRM-BTM) (except LC-60LE841E/S)
12 LANGKD192WJFW P Angle (TRM-BTM) (for LC-60LE841E/S)
13 LANGKD518WJ3W P Stand Angle, x2
14 LHLDWA176WJUZ AC J WireHolder
15 LHLDWA294WJUZ AC J WireHolder, x15
16 LHLDWA303WJKA AE J Cable Clamp
17 LHLDWA347WJKZ P WireHolder, x7
18 LX-BZA202WJF8 AA J Screw, x9
19 LX-BZA207WJF7 AA J Screw, x20
20 LX-BZA474WJF8 P Screw, x11
21 LX-NZA049WJFN AC J Screw
22 PMLT-A676WJZZ P
Gasket (HDMI)
23 PSLDMB751WJFW P MAIN PWB Shield
24 PSPAHC570WJZZ P Himeron, x2
25 PSPAKA511WJKZ P Terminal Spacer
26 PSPAZC690WJZZ P Conductr
27 PSPAZC691WJZZ AE J Conductr, x3
28 PSPAZC805WJKZ N P Cooler, x2
29 PSPAZC887WJKZ N P Shading Sheet
30 PZETKA665WJKZ N P Power Insulatio
!
31 QACCKA055WJPZ AQ J AC Cord (except LC-60LE841E)
!
31 QACCBA106WJPZ AS J AC Cord (for LC-60LE841E)
32 QCNW-M534WJZZ N P Connecting Cord (SB)
33 QCNW-M542WJZZ N P Connecting Cord (SP)
34 QCNW-M553WJQZ N P Connecting Cord (L1)
35 QCNW-M601WJQZ2 N P Connecting Cord (AS)
36 QCNW-M602WJQZ N P Connecting Cord (LW)
37 QCNW-M603WJQZ N P Connecting Cord (RC)
38 QCNW-M639WJQZ N P Connecting Cord (CI)
39 QCNW-M687WJQZ N P Connecting Cord (PD)
40 QEARPA398WJ1W N P Earth Angle
41 QEARZ0057CEFW AB J Spring
42 RCORFA061WJZZ AG J Ferrite Core, x4
43 RSP-ZA572WJZZ N P Speaker (L/R), x2
44 RSP-ZA575WJZZ N P Speaker (WOOFER)
45 TLABNC117WJZZ P Model Label
46 TLABZC453WJZZ P Plane Label
47 TLABZD176WJZZ N P Quattron Label
48 TLABZD177WJZZ N P Energy Label (except LC-60LE840RU)
49 XBPS830P06WS0 AA J Screw, x27
50 XBPS830P06WS0 AA J Screw, x18
51 XBPS830P08000 AA J Screw, x7
52 XEBS830P12000 AA J Screw, x2
53 XEBS830P12000 AA J Screw, x8
