Sharp LC-70UD1U - Page 14

LC-70UD1U
4 – 3
3. Removing of Rear Cover (L/R ) Ass'y, and Rear Cover Center, Front Cover Ass'y,
1. Remove the 10 lock screws (1) and detach the Front Cover Ass'y (2).
2. Remove the 12 lock screws (3) and detach the Rear Cover (L) Ass'y (4), the Rear Cover Center (5) and the Rear Cover (R) Ass'y (6),
3. Remove the 7 lock screws (7) and detach the 2 Speaker Unit (8), 2 Speaker Unit (Tweeter) (9) and disconnect the SP wire.
4. Detach the 3D-IR Seal Cover Ass'y (10)
5. Detach the Wi-Fi Unit (11) and disconnect the UB wire.
6. Detach the BLUETOOTH Unit (12) and disconnect the BT wire.
7. Detach the R/C OPC Unit (13) and disconnect the RA wire.
Ԙ Ԙ Ԙ Ԙ Ԙ Ԙ Ԙ Ԙ Ԙ
Ԙ
Ԛ Ԛ Ԛ Ԛ Ԛ Ԛ Ԛ Ԛ Ԛ Ԛ Ԛ Ԛ
52 52
$6
4#
7$
Ԟ Ԟ Ԟ Ԟ Ԟ Ԟ Ԟ
4#
52
-/
$6
7$
5$
ԙ(TQPV%QXGT#UU[
ԛ4GCT%QXGT.#UU[Ԝ4GCT%QXGT%GPVGTԝ4GCT%QXGT4#UU[
Ԡ5RGCMGT7PKV6YGGVGT
ԟ5RGCMGT7PKV
5RGCMGT7PKVԟ
5RGCMGT7PKV6YGGVGTԠ
㧟&+45GCN%QXGT#UU[ԡ
ԣ$.7'6116*7PKV
Ԥ4%12%7PKV
Ԣ9K(K7PKV
