No audio (3)
No audio at UHF/VHF broadcast signal reception. No audio at digital broadcast signal reception.
Is TV selected on the input select menu screen? Is TV selected on the input select menu screen?
YES
NO
YES
NO
Refer to “No video at UHF/VHF broadcast signal
reception”.
Refer to “No video at digital broadcast signal
reception”.
Does the digital audio signal come from pins(AR11/AP11/AN9)(CPU_AOBCK/AOLRCK/AOSDATA0) of IC3301(CPU) to pins(6/7/5)(SP_BCLK/
SP_LRCLK/SP_DATA) of IC1703(Audio DSP)?
YES
NO
Check the line between IC3301 and IC1703, and their paripheral circuits.
• About the L/R Speakers.
Does the digital audio signal come from pins (30/21/26/27) of IC1703 (Audio DSP) to pin (5/7/8/6) of IC1902 (AMP for L/R)?
• About the Subwoofer speaker.
Does the digital audio signal come from pins (30/21/26/28) of IC1703 (Audio DSP) to pin (5/7/8/6) of IC1901 (AMP for SW)?
YES
NO
Check IC1703 and its paripheral circuits.(X1701, etc.)
• About the L/R Speakers.
Is the audio output from IC1902 as specified?
• About the Subwoofer Speaker.
Is the audio output from IC1901 as specified?
YES
NO
• About the L/R Speakers.
Check IC1902 and its peripheral circuits.
• About the Subwoofer Speaker.
Check IC1901 and its peripheral circuits.
• About the L/R Speakers.
Check the connector (P1903) L/R speakers and their peripheral circuits.
• About the Subwoofer Speaker.
Check the connector (P1904), subwoofer speaker and their peripheral circuits.
