Sharp LC65LE541U - Page 68

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
3 21 9LE 194715009900 FOAM PAD(20.0*5.0*0.3t)(BLK) G Supplier EA 4
2 1 9LE 181201027620 PANEL SUPPORT BKT(SGCC 2.0t)(LC-65LE643U)ASS'Y G Assembly Pull EA 2
3 1 9LE 171201027620 PANEL SUPPORT BKT(SGCC 2.0t)(LC-65LE643U) G Supplier EA 1
3 1 9LE 171201027760 PANEL HOLDER BKT(SGCC 2.0t)(LC-65LE643U) G Supplier EA 1
3 11 9LE 172500040650 MAC SCREW-MB M4.0*6.0L,BLK_Ni, NYLOK G Supplier EA 4
2 1 9LE 194712000311 ACETATE CLOTH TAPE 27*75mm G Assembly Pull EA 8
2 1 9LE 194712000401 ACETATE CLOTH TAPE 20*45mm G Assembly Pull EA 20
2 41 9LE 194712009110 INSULATOR TAPE(NITTO CN-3611UL/W10)(BROWN) G Assembly Pull MZ .8
2 1 9LE 194715006620 CR SPONGE(20.0L*8.0W*3.0t) G Assembly Pull EA 1
2 1 9LE 194715009840 CR SPONGE(20.0L*10.0W*6.0t)(BLK) G Assembly Pull EA 1
2 1 9LE 194717001250 Conductive Fabric tape (L15*W34mm) G Assembly Pull EA 1
2 1 9LE 194717001270 Conductive Tape 60*40 (L type) for ESD G Assembly Pull EA 1
2 1 9LE 194717001360 Conductive Tape 25*70mm G Assembly Pull EA 2
2 1 9LE 194717001370 Conductive Tape 25*150mm G Assembly Pull EA 1
2 1 9LE 194718002750 Gasket Block L25*W12*H3mm G Assembly Pull EA 3
2 51 9LE 194718002780 Gasket Block L20*W12*3.0Hmm for ESD G Assembly Pull EA 1
2 1 9LE 194719000750 THERMAL PAD(55*12*1.5t) G Assembly Pull EA 12
2 81 9LE 194720003260 RUBBER PAD(SILICON/20*14*2.7t)(DEEP GRAY) G Assembly Pull EA 4
2 101 9LE 194724001310 MYLAR(PC DFR117/OD9.0*ID4.5*0.6t)(BLK) G Assembly Pull EA 3
2 1 9LE 194724001530 MYLAR(FRPP/383*320*0.5t)(BLK)(LC-65LE643U) G Assembly Pull EA 1
2 91 9LE 194724001710 MYLAR(PC/50*5*0.4t)(BLK)(LC-65LE643U) G Assembly Pull EA 2
2 1 9LE 363202420189 IR BD ASS'Y SHARP (LC-32RA10U_NS6738S) M Assembly Pull EA 1
3 1 9LE 363202420189M IR BD ASS'Y SHARP (LC-32RA10U_NS6738S) MI P Phantom EA 1
4 21 9LE 045112500406 WAFER 1.25mm 4P 180' DIP KINK (M24014) L-F G Assembly Pull EA 1 JR2
4 *R* 9LE 045112500403 WAFER 1.25mm 4P 180' KINK (A1251WV0-4P) L-F G EA 1
4 1 9LE 363202420189T IR BD ASS'Y SHARP (LC-32RA10U_NS6738S) TOP P Phantom EA 1
5 61 9LE 011131015117 C/M Multi. 100PF 50V X7R K 0402 G Assembly Pull EA 1 CR7
5 *R* 9LE 011231015117 C/M Multi. 100PF 50V X7R K 0402 G EA 1
5 41 9LE 011131041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 2 CR5,CR6
5 *R* 9LE 011231041617 C/M Multi. 0.1uF 16V X7R 0402 G EA 2
5 *R* 9LE 011551041617 C/M Multi. 0.1uF 16V X7R K 0402 (CL05B104KO5NNNC) G EA 2
5 1 9LE 011231061155 C/M Multi. 10uF 10V X5R 0805 L-F G Assembly Pull EA 1 CR1
5 *R* 9LE 011551061155 C/M Multi. 10uF 10V X5R 0805 G Assembly Pull EA 1
5 71 9LE 013018001654 RES. CF 180ohm 1/16W J 0402 G Assembly Pull EA 1 RR1
5 1 9LE 013047091858 RES. CF 47ohm 1/8W J 0805 G Assembly Pull EA 1 LR1
5 51 9LE 017116711145 PCB IR BD FR4 54*8*1.6t 2L (SHARP A+)(1:20) G Assembly Pull EA 1
5 1 9LE 044040000206 LED White TOP VIEW (LTW-C191UC5) 1.6*0.8*0.55mm SMD HF G Assembly Pull EA 1 LED1
5 1 9LE 098002006050 IR RECEIVER 38KHz 4pin 5.2x4x2.8mm SMD(NS6738S) LF G Assembly Pull EA 1 UR1
5 *R* 9LE 098002006031 IR RECEIVER 38KHz 4pin SMD 5.2x4x2.8mm R1.0(FM-A438FN-5CN)LF G EA 1
2 1 9LE 365500720156 DISPLAY BD ASS'Y LC-55LE643U (Screw V1,V2) M Assembly Pull EA 1
3 1 9LE 365500720156M DISPLAY BD ASS'Y LC-55LE643U (Screw V1,V2) MI P Phantom EA 1
4 1 9LE 022070203265 SW TACT 4.5*4.5mm 180' 160g DIP SFKHRAA2220P L-F G Assembly Pull EA 7 SW1,SW2,SW3,SW4,SW5,SW6,SW7
4 1 9LE 045112500466 WAFER 1.25mm 4P 90' DIP KINK (M24014R) L-F G Assembly Pull EA 1 J1
4 *R* 9LE 045112500463 WAFER 1.25mm 4P 90' KINK (A1251WR0-4P) L-F G Assembly Pull EA 1
4 1 9LE 365500720156T DISPLAY BD ASS'Y LC-55LE643U (Screw V1,V2) TOP P Phantom EA 1
5 1 9LE 011131031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 2 C2,C3
5 *R* 9LE 011231031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 2
5 *R* 9LE 011551031617 C/M Multi. 0.01uF 16V X7R 0402 (CL05B103KO5NNN) G Assembly Pull EA 2
5 1 9LE 011231051656 C/M MULTI 1.0uF 16V X5R 0603 G Assembly Pull EA 1 C1
5 *R* 9LE 011551051656 C/M MULTI 1.0uF 16V X5R 0603 G Assembly Pull EA 1
5 *R* 9LE 011131051656 C/M MULTI 1.0uF 16V X5R 0603 G Assembly Pull EA 1
5 1 9LE 013000001654 RES. CF 0ohm 1/16W J 0402 G Assembly Pull EA 3 R15,R16,R22
