Sharp LC65LE541U - Page 69

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
5 1 9LE 013010011654 RES. CF 1Kohm 1/16W J 0402 G Assembly Pull EA 2 R18,R20
5 1 9LE 013120011614 RES. MF 2Kohm 1/16W F 0402 G Assembly Pull EA 6 R10,R19,R2,R21,R3,R9
5 1 9LE 013124011614 RES. MF 2.4Kohm 1/16W F 0402 G Assembly Pull EA 1 R7
5 1 9LE 017117712870 PCB Display BD FR4 109*14*1.6t*2L (JVC EM55T)(1:10) G Assembly Pull EA 1
2 1 9LE 366500320304 LCM ASS'Y LC-65LE541U (AUO T650HVN05.5) P Phantom EA 1
3 1 9LE 021506500277 Open cell ASS'Y T650HVN05.5 (AUT) G Assembly Pull EA 1
3 1 9LE 046010020221 A2001-2/A2001-2 10368#26 150mm(B) G/Y HF G Assembly Pull EA 4
3 1 9LE 046011080201 A2512-8/PK242151P2*4 10368#26 600/400/500/700(A) HF G Assembly Pull EA 1
3 1 9LE 098102657702 55.65T07.C12 T-CON ASS'Y for T650HVN05.5 (AUT) G Assembly Pull EA 1
3 1 9LE 170114000950 SNAP BUSHING(L27.6*W14*13.3t)(BLK) G Assembly Pull EA 5
3 1 9LE 170115003890 SPACER SUPPORT(MB-32PC5V0) G Assembly Pull EA 36
3 1 9LE 170115004120 SPACER SUPPORT(MCFA-2511) G Assembly Pull EA 11
3 1 9LE 171201027900 PANEL SUPPORT BKT_INNER(SGCC 1.6t)(LC-65LE643U) G Assembly Pull EA 2
3 1 9LE 171303011010 BOTTOM COVER(SECC 0.8t)(EM65FTR) G Assembly Pull EA 1
3 21 9LE 172050030450 MAC. SCREW-MI M3.0*4.0L, BLK-Ni G Assembly Pull EA 12
3 1 9LE 180119821010 GUIDE PANEL_T(PC+GF10 FR/T52013)(EM65FTR)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119821000 GUIDE PANEL_T(EM65FTR) G Supplier EA 1
4 1 9LE 170119821010 GUIDE PANEL_T(PC+GF10 FR/T52013)(EM65FTR) G Supplier EA 1
4 1 9LE 194715009650 FOAM PAD(1265.0*3.0*0.4t)(BLK) G Supplier EA 1
4 1 9LE 194720003130 RUBBER PAD(SILICON/1285*3*1.0t)(DEEP GRAY) G Supplier EA 1
3 1 9LE 180119822011 GUIDE PANEL_B(PC+GF10 FR/T52013)(EM65FTR)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119822000 GUIDE PANEL_B(EM65FTR) G Supplier EA 1
4 1 9LE 170119822010 GUIDE PANEL_B(PC+GF10 FR/T52013)(EM65FTR) G Supplier EA 1
4 1 9LE 194715009650 FOAM PAD(1265.0*3.0*0.4t)(BLK) G Supplier EA 1
4 1 9LE 194720003130 RUBBER PAD(SILICON/1285*3*1.0t)(DEEP GRAY) G Supplier EA 1
3 31 9LE 180119823011 GUIDE PANEL_L(PC+GF10 FR/T52013)(EM65FTR)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119823000 GUIDE PANEL_L(EM65FTR) G Supplier EA 1
4 1 9LE 170119823010 GUIDE PANEL_L(PC+GF10 FR/T52013)(EM65FTR) G Supplier EA 1
4 1 9LE 194715009660 FOAM PAD(80.0*3.0*0.4t)(BLK) G Supplier EA 2
4 1 9LE 194715009670 FOAM PAD(815.0*3.0*0.4t)(BLK) G Supplier EA 1
4 1 9LE 194715009730 FOAM PAD(36*6.0*0.3t)(BLK) G Supplier EA 6
4 1 9LE 194720003120 RUBBER PAD(SILICON/815*3*1.0t)(DEEP GRAY) G Supplier EA 1
4 1 9LE 194720003140 RUBBER PAD(SILICON/72*3*1.0t)(DEEP GRAY) G Supplier EA 2
4 1 9LE 194724001720 MYLAR(PC/35*5*0.4t)(BLK)(LC-65LE643U) G Supplier EA 2
3 41 9LE -180119824011 GUIDE PANEL_R(PC+GF10 FR/T52013)(EM65FTR)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119824000 GUIDE PANEL_R(EM65FTR) G Supplier EA 1
4 1 9LE 170119824010 GUIDE PANEL_R(PC+GF10 FR/T52013)(EM65FTR) G Supplier EA 1
4 1 9LE 194715009660 FOAM PAD(80.0*3.0*0.4t)(BLK) G Supplier EA 2
4 1 9LE 194715009670 FOAM PAD(815.0*3.0*0.4t)(BLK) G Supplier EA 1
4 1 9LE 194715009730 FOAM PAD(36*6.0*0.3t)(BLK) G Supplier EA 6
4 1 9LE 194720003120 RUBBER PAD(SILICON/815*3*1.0t)(DEEP GRAY) G Supplier EA 1
4 1 9LE 194720003140 RUBBER PAD(SILICON/72*3*1.0t)(DEEP GRAY) G Supplier EA 2
4 1 9LE 194724001720 MYLAR(PC/35*5*0.4t)(BLK)(LC-65LE643U) G Supplier EA 2
3 1 9LE 194712000401 ACETATE CLOTH TAPE 20*45mm G Assembly Pull EA 21
3 11 9LE 194712009210 PET TAPE(3M SUPER10/30.0L*25.0W*0.06t)(TRANSPARENT) G Assembly Pull EA 5
3 1 9LE 194717001270 Conductive Tape 60*40 (L type) for ESD G Assembly Pull EA 1
3 1 9LE 194724001610 MYLAR(PC/27.0*12.0*0.125t)(BLACK) G Assembly Pull EA 16
3 1 9LE 36650042030C BLACKLIGHT ASS'Y LC-65LE541U (Nitride LED) P Phantom EA 1
4 1 9LE 0981010221AD 65 inch L/B module 8PCS- A(Nitride LED_AUO 5.5/5.8) G Assembly Pull EA 8
4 1 9LE 0981010221AE 65 inch L/B module 8PCS- B(Nitride LED_AUO 5.5/5.8) G Assembly Pull EA 4
4 1 9LE 0981010221AF 65 inch L/B module 8PCS- C(Nitride LED_AUO 5.5/5.8) G Assembly Pull EA 4
4 1 9LE 170109004030 DIFFUSER SHEET UP-CELL1(CH194K/PET 0.265t)(LC-65LE643U) G Assembly Pull EA 1
