Sharp LC65LE541U - Page 75

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
6 1 9LE 039050034293 DUAL SURFACE DIODE BAV70-7-F SMD (SOT-23) L-F G Assembly Pull EA 3 DA1,DA5,DV1
6 *R* 9LE 039050073273 DUAL SURFACE DIODE BAV70 SMD SOT-23 HF G Assembly Pull EA 3
6 1 9LE 039050042343 GEN. DIODE LL4148WP (CD4148WP) SMD 1206 LF G Assembly Pull EA 5 DA2,DI2,DL1,DM1,DP5
6 *R* 9LE 039050071293 DIODE FAST 0.3A 100V 1N4148W-7-F SOD-123 LF G Assembly Pull EA 5
6 1 9LE 039060073413 SCHOTTKY DIODE 5A 40V SM540C SMC LF G Assembly Pull EA 1 DP2
6 *R* 9LE 039060073103 SCHOTTKY DIODE 5A 40V MBRS540T3G SMC LF G Assembly Pull EA 1
6 *R* 9LE 039060073293 SCHOTTKY DIODE 5A 40V B540C-13-F SMC LF G Assembly Pull EA 1
6 1 9LE 039060086413 SCHOTTKY DIODE 0.2A 30V SCS520S SOD-523 2PIN LF G Assembly Pull EA 1 DA6
6 *R* 9LE 039060086203 SCHOTTKY DIODE 0.2A 30V RB520S- 30F SOD-523 LF G Assembly Pull EA 1
6 1 9LE 040005415012 ZENER 5.49~5.73V UDZSTE-175.6B 1/5W SOD-323 G Assembly Pull EA 1 ZD1
6 *R* 9LE 040005415717 ZENER 5.49~5.73V KDZ5.6VY 1/5W SOD-323 LF G Assembly Pull EA 1
6 1 9LE 040011715012 ZENER 11.74~12.24V UDZSTE-1712B 1/5W SOD-323 LF G Assembly Pull EA 1 ZDA3
6 *R* 9LE 040011415015 ZENER 11.4~12.7V BZT52C12S-7-F 1/5W SOD-323 LF G Assembly Pull EA 1
6 1 9LE 040013815713 ZENER 13.8-15.6V BZT52C15S-7-F 1/5W SOD-323 LF G Assembly Pull EA 1 ZDL1
6 *R* 9LE 040014215010 ZENER 14.25-15.75V MM3Z15VCWF 1/5W SOD-323 LF G Assembly Pull EA 1
6 1 9LE 041050005638 TR NPN 0.2A 40V LMBT3904LT1G SOT-23 HF G Assembly Pull EA 9 QA1,QA3,QA4,QH8,QH9,QI2,QL1,QM3,QP10
6 *R* 9LE 041050005643 TR NPN 0.2A 40V METR3904-G SOT-23 HF G Assembly Pull EA 9
6 1 9LE 042020073636 MOSFET P-CH 9.5A 30V SSG4835P SOP 8PIN LF G Assembly Pull EA 1 UL2
6 *R* 9LE 042020093642 MOSFET P-CH 9A 30V APM4317KC-TRG SOP-8 HF G Assembly Pull EA 1
6 1 9LE 042020092643 MOSFET P-CH 3.2A 30V ME2303-G SOT-23 HF G Assembly Pull EA 1 QP4
6 *R* 9LE 042020058629 MOSFET P-CH 3.7A 30V AP2309GN SOT-23 3PIN LF G Assembly Pull EA 1
6 *R* 9LE 042020091642 MOSFET P-CH 4A 30V APM2303AC-TRG SOT-23-3 HF G Assembly Pull EA 1
6 1 9LE 043000016609 IC CMOS LOGIC 74HC4052PW TSSOP 16PIN LF G Assembly Pull EA 1 UH4
6 *R* 9LE 043000038686 IC CMOS ANALOG U74HC4052G-P16-R TSSOP-16 HF G Assembly Pull EA 1
6 1 9LE 043000047015 IC CMOS CD74HC4094M96 SOIC-16 LF G Assembly Pull EA 2 U2,U3
6 *R* 9LE 043000047009 IC CMOS 74HC4094D SO-16 LF G Assembly Pull EA 2
6 1 9LE 043030149045 IC SERIAL FLASH 8M MX25L8006EM2I-12G SOP-8 LF G Assembly Pull EA 1 UM2
6 1 9LE 043030163045 IC SERIAL FLASH 32M MX25L3206EM2I-12G SOP-8 LF G Assembly Pull EA 1 US4
6 1 9LE 043050318985 IC MEMC MST7438BB EPLQFP-128 HF G Assembly Pull EA 1 UM1
6 1 9LE 043060270079 IC LDO 1A ADJ AP1117EG-13 SOT223-3L 3PIN HF G Assembly Pull EA 2 UP3,UP4
6 *R* 9LE 043060345075 IC LDO 1A ADJ AX1007EA SOT223-3L HF G Assembly Pull EA 2
6 1 9LE 0430604260C1 IC STEP-DOWN CONV 3A 23V FR9889SPCTR SOP-8 LF G Assembly Pull EA 1 UP17
6 *R* 9LE 043060424044 IC STEP-DOWN DC/DC CONV 3A 23V IT76630M SOP8-EP LF G Assembly Pull EA 1
6 1 9LE 043060437039 IC STEP-DOWN CONV 1.5A 6V LA8013ACD SOT-23-5 LF G Assembly Pull EA 4 UP15,UP16,UP18,UP19
6 1 9LE 043060440015 IC STEP-DOWN CONV 5A 28V TPS54531DDAR SOIC-8 PowerPAD HF G Assembly Pull EA 1 UP2
6 1 9LE 043070865615 IC AUDIO OP DRV632PWR TSSOP-14 HF G Assembly Pull EA 1 UA2
6 1 9LE 043070921721 IC AUDIO DSP NPCA110DA0YX QFN-32 LF G Assembly Pull EA 1 UW1
6 1 9LE 043070942715 IC AUDIO POWER AMP 20W TAS5707LPHPR HTQFP-48 HF G Assembly Pull EA 1 UA1
6 1 9LE 043070956079 IC RESET 4.38V APX810-44SAG-7 SOT-23 HF G Assembly Pull EA 1 US1
6 1 9LE 043140020999 IC SCALER MSD8220LBP W/O DDP EPLQFP-156 HF G Assembly Pull EA 1 U1
6 11 9LE 099130072800 SW SHARP LC-65LE541U Mstar8220_AUO 099130072800 (1002-4353) G Supplier EA 1 US41X
6 1 9LE 366501020150B MAIN BD ASS'Y LC-65LE541U_MX (AUO T650HVN05.5) BOT P Phantom EA 1
7 1 9LE 011131041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 35
C121,C130,C131,C132,C133,C135,C136,C143,C145,C150,C155,CM10,CM14,
CM15,CM19,CM2,CM20,CM27,CM29,CM3,CM31,CM36,CM37,CM38,CM46,C
M47,CM49,CM5,CM6,CM7,CM8,CW1,CW2,CW3,CW4
7 *R* 9LE 011231041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 35
Confidential-do not copy
Page 14-10
File No. SG-0000244
