Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
7 *R* 9LE 011551041617 C/M Multi. 0.1uF 16V X7R K 0402 (CL05B104KO5NNNC) G Assembly Pull EA 35
7 1 9LE 011131042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 6 CA45,CA49,CA61,CA62,CA64,CA65
7 *R* 9LE 011231042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 6
7 *R* 9LE 011551042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 6
7 1 9LE 011231051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 3 CA79,CH18,CH19
7 *R* 9LE 011551051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 3
7 *R* 9LE 011131051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 3
7 1 9LE 011231061155 C/M Multi. 10uF 10V X5R 0805 L-F G Assembly Pull EA 4 C120,CM22,CM35,CM56
7 *R* 9LE 011551061155 C/M Multi. 10uF 10V X5R 0805 G Assembly Pull EA 4
7 1 9LE 013000001654 RES. CF 0ohm 1/16W J 0402 G Assembly Pull EA 10 R188,RH54,RH61,RH62,RH63,RH64,RM1,RM13,RM14,RM6
7 1 9LE 013000001858 RES. CF 0.0ohm 1/8W J 0805 G Assembly Pull EA 2 FB2,R39
7 1 9LE 013010021654 RES. CF 10Kohm 1/16W J 0402 G Assembly Pull EA 11 R31,R32,R33,R34,R35,R36,R37,R38,RA92,RH68,RH69
7 1 9LE 013012031654 RES. CF 120Kohm 1/16W J 0402 G Assembly Pull EA 1 RP74
7 1 9LE 013047011654 RES. CF 4.7Kohm 1/16W J 0402 G Assembly Pull EA 2 RS29,RS30
7 1 9LE 013047021654 RES. CF 47Kohm 1/16W J 0402 G Assembly Pull EA 3 RH34,RH38,RH65
7 1 9LE 013139201614 RES. MF 392ohm 1/16W F 0402 G Assembly Pull EA 1 RM73
7 1 9LE 017122715502 PCB MAIN BD FR4 185*141*1.2t 2L (LC-65LE643U)(1:2) G Assembly Pull EA 1
7 1 9LE 037000014252 BEAD 80ohm 6A 0805 GMLB-201209-0080P-N8B HF G Assembly Pull EA 7 FB10,FB5,FB6,FB7,FB8,FBH6,LA2
7 *R* 9LE 037000014282 CHIP BEAD 80ohm 6A 0805 (GB201212K800TM) LF G Assembly Pull EA 7
7 1 9LE 039060050293 Schottky Diode 0.2A 30V BAT54C-7-F SOT-23 HF G Assembly Pull EA 1 DV2
7 *R* 9LE 039060110273 Schottky Diode 0.2A 30V BAT54C SOT-23 HF G Assembly Pull EA 1
7 1 9LE 043071043079 IC POWER SWITCH 2.1A AP2191WG-7 SOT-23-5 HF G Assembly Pull EA 1 UH3
7 *R* 9LE 043071050071 IC POWER SWITCH 1.5A APL3551CBI-TRG SOT-23-5 HF G Assembly Pull EA 1
**** END ****
Confidential-do not copy
Page 14-11
File No. SG-0000244
