: Preautomatic adjustment menu Adjustment error : Preadjustment error (adjustment value output) : During preautomatic adjustment
Adjustment error
Normal end
: Preadjustment normal end (adjustment value output)
: During ATT automatic adjustment
PLAY
PLAY
A U T O 1
Servo Preautomatic Adjustment
A D J . O K
A D J . N G
A T 2
A T 1
* When the [STOP] button is pressed in specific menu, the "TEST MODE STOP" state is set. * Move the pickup lens manually to the innermost periphery before performing the servo preliminary auto adjustment. (Refer to "Change of test mode menus" for the operation method.) * " " is theinternal processing number, the meanings of the numbers are as follows.
0 0 : Sled innermost periphery move 0 2 : ABEF input offset measurement 0 4 : AB input (ABMAXO) level setting 0 5 : Focus ATT tentative setting 0 6 : Pit section EF input level setting 0 7 : COUT level setting for pit section adjustment 0 8 : Sled external periphery move 0 9 : Groove section EF input level setting 1 0 : COUT level setting for groove section adjustment 1 1 : TCRS input level setting 1 2 : Tracking ATT initial setting 1 3 : AB input (LPFABO) level setting 1 4 : Focus ATT initial setting 1 6 : TCRS input offset measurement
* It is necessary for each test mode where servo operation is made to complete the preliminary adjustment. (Otherwise, "ErADJ." appears.) * The preliminary adjustment complete state is stored on the EEPROM (protected field).
: ATT auto adjustment menu : ATT adjustment error (adjustment value output) : During ATT auto adjustment
Adjustment error
Normal end
: ATT adjustment error (adjustment value output)
: Continuous playback (high reflection) : Continuous playback (low reflection)
PLAY
PLAY
A U T O 2
Servo ATT Auto Adjustment
A D J . O K
A D J . N G
S Q # # # # A P # # # #
A T 2
* When the [STOP] button is pressed in specific menu, the "TEST MODE STOP" state is set. * Move the pickup lens manually to the innermost periphery before performing the servo ATT auto adjustment. (Refer to "Change of test mode menus" for the operation method.) * " " represent the adjustment number as follows.
0 0 : Sled innermost periphery move 0 3 : Pit section tracking ATT setting 0 4 : Pit section focus ATT setting 0 6 : Sled external periphery move (low reflection only) 0 7 : TCRS ATT setting (low reflection only) 0 8 : Groove section tracking ATT setting (low reflection only) 0 9 : Groove section focus ATT setting (low reflection only)
