Sharp MX-2600N Safety Guide

10
SPECIFICATIONS
Acoustic noise emission (measurement according to ISO7779)
Automatic document feeder specifications
* Scanning in mono 2 mode of one side only is possible in fax and scan send modes. However, when the resolution is 600 x 600 dpi
in Internet fax mode, the maximum length is 800 mm (31-31/64"). When the resolution is 400 x 400 dpi or 600 x 600 dpi in scan
mode, a long original cannot be scanned.
Sound power level L
wA
Printing mode (continuous printing)
MX-2600N: 6.7 B MX-3100N: 6.7 B
Standby mode
MX-2600N: 5.8 B MX-3100N: 5.8 B
Sound pressure level LpA (actual measurement)
Printing mode
Bystander positions
MX-2600N Colour: 51 dB (A) Black and white: 51 dB (A)
MX-3100N Colour: 51 dB (A) Black and white: 51 dB (A)
Operator positions
MX-2600N Colour: 51 dB (A) Black and white: 50 dB (A)
MX-3100N Colour: 51 dB (A) Black and white: 51 dB (A)
Standby mode
Bystander positions
MX-2600N: 26 dB (A)
MX-3100N: 25 dB (A)
Operator positions
MX-2600N: 24 dB (A)
MX-3100N: 24 dB (A)
Original sizes
A3 to A5, 11" x 17" to 5-1/2" x 8-1/2", long paper
(max. width 297 mm (11-5/8") x max. length 1000 mm* (39-23/64"), scanning in mono 2 mode of
one side only is possible in fax and image scan modes)
Original weight
One-sided 35 g /m
2
to 128 g /m
2
(9 lbs. to 32 lbs.) (Paper weights from 35 g /m
2
(9 lbs.) to 49 g /m
2
(13 lbs.) require the use of slow scan mode.)
Two-sided 50 g /m
2
to 105 g /m
2
(13 lbs. to 28 lbs.)
Capacity
100 sheets (80 g/m
2
(21 lbs.)) Maximum stack height of 13 mm (33/64")

Sharp MX-2600N Specifications

Power

power requirements	230 ~240V AC, 50/60 Hz
power consumption	1.84 kW
warm-up time	Less than 60 sec.

System Memory

copier memory	Standard 1, 024MB, max. 2, 048MB
printer memory	Standard 512MB, max. 1, 536MB
HDD	80GB

Paper Handling

standard paper capacity	1, 100 sheets
maximum paper capacity	5, 600 sheets
paper weight (tray)	60 g/m² to 209 g/m²

Weight and Dimensions

dimensions	620 x 695 x 950 mm
weight	Approx. 112 kg
