Sharp MX-2600N Safety Guide

14
SPECIFICATIONS
Saddle stitch finisher specifications*
1
*1 Paper pass unit and stand/1x500 sheet paper drawer or stand/2x500 sheet paper drawer are required to connect the saddle stitch
finisher to the machine.
*2 The maximum number of sheets that can be held varies depending on ambient conditions in the installation location, the type of
paper, and the storage conditions of the paper.
*3 Up to 30 envelopes can be output.
*4 The height of the sheets must not exceed 175 mm (6-57/64").
*5 The height of the sheets must not exceed 94 mm (3-45/64").
*6 The maximum number of sheets for stapling assumes a paper weight of 90 g/m
2
(24 lbs.) and includes two cover sheets of
106 g/m
2
to 256 g/m
2
(28 lbs. bond to 140 lbs. index).
*7 Allowed paper weights for saddle stitch stapling of plain paper include heavy paper (106 g /m
2
to 256 g /m
2
(28 lbs. bond to 140 lbs. index)).
Model
MX-FN10
Paper sizes
A3W, A3, B4, A4, A4R, B5, B5R, A5R, envelopes, 12" x 18", 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2",
8-1/2" x 13-2/5", 8-1/2" x 13", 8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 5-1/2" x 8-1/2"R, 8K, 16K,
16KR
Paper weight
Thin paper (55 g /m
2
to 59 g /m
2
(15 lbs. to 16 lbs.)) plain paper (60 g /m
2
to 105 g /m
2
(16 lbs. to 28 lbs.)) heavy
paper (106 g /m
2
to 256 g /m
2
(28 lbs. bond to 140 lbs. index)), envelopes (75 g /m
2
to 90 g /m
2
(20 lbs. to 24 lbs.))
Modes
Non-staple, staple, saddle stitch, half fold (Output is folded in half one sheet at a time.)
Allowed paper sizes for offset
A3, A4, A4R, B4, B5, B5R, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13",
8-1/2" x 11", 8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 8K, 16K, 16KR
Offset distance
30 mm (1-3/16")
Tray capacity*
2
Non-stapling*
3
:
1000 sheets*
4
(A4, A4R, B5, B5R, 8-1/2" x 11",
8-1/2" x 11"R, 7-1/4" x 10-1/2"R, 16K, 16KR)
500 sheets*
5
(A3W, A3, B4, A5R, 12" x 18",
11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2",
8-1/2" x 13-2/5", 8-1/2" x 13", 5-1/2" x 8-1/2"R,
8K)
Stapling*
6
:
50 sets or 1000 sheets*
4
(A4, A4R, B5, B5R,
8-1/2" x 11", 8-1/2" x 11"R, 16K, 16KR)
50 sets or 500 sheets*
5
(A3, B4, 11" x 17",
8-1/2" x 14",
8-1/2" x 13-1/2", 8-1/2" x 13-2/5",
8-1/2" x 13", 8K)
Power supply
Supplied from the machine
Dimensions
497 mm (W) x 631 mm (D) x 988 mm (H) (19-9/16" (W) x 24-27/32" (D) x 38-57/64" (H))
(When tray is folded up)
Weight
Approx. 40 kg (88.2 lbs.)
Overall dimensions when
attached to machine
1638 mm (W) x 683 mm (D) (64-15/32" (W) x 26-57/64" (D)) (When tray is extended)
Stapler section
Allowed paper sizes for
stapling
A3, B4, A4, A4R, B5, B5R, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13",
8-1/2" x 11", 8-1/2" x 11"R, 8K, 16K, 16KR
(Three stapling positions: one staple at bottom left corner, one staple at top left corner, and two staples.)
Maximum number of
sheets for stapling*
6
50 sheets (A4, A4R, B5, B5R, 8-1/2" x 11", 8-1/2" x 11"R, 16K, 16KR)
25 sheets (A3, B4, 11" x 17", 8-1/2" x 14", 8-1/2" x 13-1/2", 8-1/2" x 13-2/5", 8-1/2" x 13", 8K)
(25 sheets when the sheets are the same width but different lengths.)
Saddle stitch section
Stapling method
Fold in half and staple in two places on centreline
Folding position
Fold at centreline (can be adjusted with [Saddle Stitch Position Adjust] in the System Settings)
Allowed paper sizes for
saddle stitch stapling
A3, B4, A4R, 11" x 17", 8-1/2" x 14", 8-1/2" x 11"R, 8K, 16KR
Allowed paper weights for
saddle stitch stapling
55 g/m
2
to 256 g/m
2
(15 lbs. bond to 140 lbs. index)*
7
Number sheets for saddle
stitch stapling / Number of sets
Maximum: 15 sheets (80 g/m
2
(21 lbs.) x 14 sheets + 209 g/m
2
(110 lbs. index) x 1 sheet) / 10 sets
(11 to 15 sheets), 15 sets (6 to 10 sheets), 20 sets (1 to 5 sheets)
Note:
Special media such as transparency film and label sheets cannot be stapled or punched.

Sharp MX-2600N Specifications

Power

power requirements	230 ~240V AC, 50/60 Hz
power consumption	1.84 kW
warm-up time	Less than 60 sec.

System Memory

copier memory	Standard 1, 024MB, max. 2, 048MB
printer memory	Standard 512MB, max. 1, 536MB
HDD	80GB

Paper Handling

standard paper capacity	1, 100 sheets
maximum paper capacity	5, 600 sheets
paper weight (tray)	60 g/m² to 209 g/m²

Weight and Dimensions

dimensions	620 x 695 x 950 mm
weight	Approx. 112 kg
