MX-5001N ADJUSTMENTS 5 – 64
• Relationship between the factory target and the service target and the color balance target for the user color balance adjustment in the copy
color balance adjustment (SIM 46-24)
Type Descriptions
A Factory color
balance (gamma)
target
There are three kinds of the color balance target,
and each of them is specified according to the
machine design. Use SIM 63-11 to select one of
them as the factory target. The default setting
(factory setting) is the color balance (DEF1)
which emphasizes color reproduction.
B Service color
balance (gamma)
target
This target is used when the user requests to
customize the color balance to user's desired
level. In advance, the user's unique color balance
must be registered as the service color balance
target. The above registration (setting) is made
by the serviceman with SIM 46-21 to adjust the
color balance and with SIM 63-7 to register it.
This color balance target is used when the user
executes the color balance adjustment. When,
therefore, the service color balance target is
changed, the color balance target of the user's
color balance adjustment is also changed. When,
however, SIM 63-8 is executed, the color balance
is set to the factory color balance target set with
SIM 63-11. The default setting (factory setting) of
the color balance is same as the factory color
balance target. (Emphasized on color
reproduction (DEF1))
If the user does not request for customizing the
color balance, be sure to use SIM 63-8 to set the
color balance to the factory color balance target
C User color
balance (gamma)
target
Same color balance as the service color balance
(gamma) target When the service color balance
target is changed, this color balance target is also
changed accordingly.
Type Descriptions
Use SIM 63-11 to select one of the three
kinds of color balance targets.
Factory color balance
target (DEF1)
Factory color balance
target (DEF2)
Factory color balance
target (DEF3)
Color balance target in the copy color balance
automatic adjustment (SIM 46-24)
Factory color balance
target (one of DEF1 - 3)
Execute SIM 63-8.
(The service color balance target is the
same as the factory color balance target.)
Factory setting
Factory color balance
target (DEF1)
=
=
Color balance target in the user color balance adjustment
Color balance target for
the user color balance
adjustment
Service color balance
target
Service color balance
target
Service color balance
target
Service color balance
target (Unique)
=
Factory color balance
target
(one of DEF1 - 3)
Use SIM 46-21 to adjust the optional color
balance, and use SIM 63-7 to register it.
