MX-5001N SPECIFICATIONS 2 – 1
MX-5001N
Service Manual
[2] SPECIFICATIONS
1. Basic specifications
A. Base engine
(1) Type
(2) Engine composition
(3) Dimensions / Weight
(4) Warmup
* Condition: After the door has been opened for 60 seconds and
the polygon motor has stopped.
(5) First copy time
* Measurement conditions: When paper of A4/8.5 x 11 is fed to
narrow side direction from the main unit tray 1, and the polygon
motor is rotating.
Color auto judgment/magical view OFF.
The first output immediately after turning ON the power is
excluded.
(6) Engine resolution
(7) Printable area
Full A3 / 11 X 17 dimension (299 x 450 mm) can be printed with
PCL / PS driver.
(8) Engine speed (ppm)
a. In case of tray (1-4, LCC) paper feeding
* LCC - Supported paper types and weights: 8.5 x 11, A4, B5:
60 - 105 g/m
2
(16 - 28 LB.)
Type Desktop
Photoconductor kind OPC (Drum diameter: φ30mm)
Black x 1, Color x 3
Copying method Electronic photo (Laser)
Developing system Dry, 2-component magnetic brush
development
Charging system Charged saw-tooth method
Transfer system Intermediate transfer belt
Cleaning system Counter blade
Fusing system Heat roller
Waste toner disposal No toner recycling system / Waste toner
bottle system
Outer dimensions
(W x D x H)
MX-4100N/5000N (RSPF model):
25-25/64 x 27-23/64 x 37-25/64 inch
645 x 695 x 950 mm
MX-4101N/5001N (DSPF model):
25-25/64 x 27-23/64 x 37-25/32 inch
645 x 695 x 960 mm
Dimensions occupied by
Machine (W x D)
(State of the manual paper
feed tray is expansion.)
39-11/64 x 27-23/64 inch
995 x 695 mm
Weight
(Including OPC drum/
excluding consumble parts)
MX-4100N/5000N (RSPF model):
Approx. 253 lbs (115 kg)
MX-4101N/5001N (DSPF model):
Approx. 273 lbs (124 kg)
Warm-up time MX-4100N/4101N: 120 seconds or less
MX-5000N/5001N: 140 seconds or less
(The value may be increased by operating
condition)
Pre-heat Yes
Recovery time from jam * 30 sec. or less
Platen/
RSPF
MX-4100N/4101N
MX-5000N/5001N
Monochrome Color
Monochrome Color
Platen 4.7 sec.
or less
6.7 sec.
or less
4.1 sec.
or less
5.9 sec.
or less
RSPF 10.1 sec.
or less
13.5 sec.
or less
9.3 sec.
or less
13.5 sec.
or less
DSPF 9.5 sec.
or less
15.2 sec.
or less
8.8 sec.
or less
15.2 sec.
or less
1
1
1
Writing resolution Copy: 600 x 600dpi
Print: 1200 x 1200dpi
Smoothing No
Gradation
(Monochrome/Color)
Copy: 600 x 600dpi
Print : 600 x 600 (1bit)
/ 600 x 600 (4bit)
/ 1200 x 1200 (1bit)
Max. print size 299 x 450 mm
Void area Image loss Lead edge: 4mm or less
Rear edge: 2 mm or more, and 5 mm or less
Total of the lead edge and the rear edge:
8mm or less
Paper type Paper size
Monochrome Color
MX-
4100N/
4101N
MX-
5000N/
5001N
MX-
4100N/
4101N
MX-
5000N/
5001N
Standard
paper
A3 19
22 19 22
B4 22
25 22 25
A4
41
50 41 50
B5
A4R
26
30 26 30
B5R
A5R 29
32 29 32
Extra 18
21 18 21
11 x 17 19
22 19 22
8.5 x 14
22
25 22 25
8.5 x 13
8.5 x 13.4
8.5 x 13.5
8.5 x 11 41
50 41 50
8.5 x 11R
26
30 26 30
7.25 x 10.5R
5.5 x 8.5R 29
32 29 32
Heavy paper A4
17
17 17 17
B5
A5R
8.5 x 11
8.5 x 5.5R
A4R
13
13 13 13
B5R
8.5 x 11R
7.25 x 10.5R
In the other sizes 10
10 10 10
1
: Oct. 24 2008
1
