Sharp MX-4100N Service Manual

MX-5001N SPECIFICATIONS 2 – 3
D. Scanner section
(1) Resolution/Gradation
(2) Document table
(3) Automatic document feeder
Scanning
Resolution (dpi)
copy mode
Platen Monochrome 600 x 300 dpi (Default)
600 x 400 dpi
600 x 600 dpi
Color 600 x 600dpi
RSPF Monochrome 600 x 400 dpi (Default)
600 x 600 dpi
Color 600 x 600dpi
DSPF Monochrome 600 x 300 dpi (Default)
600 x 400 dpi
600 x 600 dpi
Color 600 x 600dpi
In sending
Resolution (dpi)
Scanner Internet Fax / Direct SMTP Fax
100dpi x 100dpi
200dpi x 100dpi
(middle tone not allowed)
Standard
(203.2 x 97.8 dpi)
(middle tone not allowed)
200dpi x 200dpi 200dpi x 200dpi
Fine
(203.2 x 195.6 dpi)
300dpi x 300dpi 200dpi x 400dpi
Super Fine
(203.2 x 391 dpi)
400dpi x 400dpi 400dpi x 400dpi
Ultra Fine
(406.4 x 391 dpi)
600dpi x 600dpi 600dpi x 600dpi ---
Exposure lamp Xenon
Reading gradation 10bits
Output gradation B/W: 1bit
Gray scale: 8bit
Full color: RGB colors are 8bit each
Type Document table fixed system (Flat bed)
Scanning area 297 x 432mm
Original standard position Left bottom reference
Detection Yes
detection size Automatic detection
Platen
Inch-1 11 x 17, 8.5 x 14, 8.5 x 11, 8.5 x 11R, 5.5 x 8.5
Inch-2 11 x 17, 8.5 x 13, 8.5 x 11, 8.5 x 11R, 5.5 x 8.5
Inch-3 11 x 17, 8.5 x 13.4, 8.5 x 11, 8.5 x 11R, 5.5 x 8.5
AB-1 A3, B4, A4, A4R, B5, B5R, A5
AB-2 A3, A4, A4R, B5, B5R, A5, 8.5 x 13
AB-3 8K, 16K, 16KR, B4, A4, A4R, A5
AB-4 A3, A4, A4R, B5, B5R, A5, 8.5 x 13.4
AB-5 A3, A4, A4R, B5, B5R, A5, 8.5 x 13.5
Dehumidifying heater
(Scanner section)
Supplied as a service part
DKIT-0373FCZZ
Type RSPF (Reversing single pass feeder)
Scan speed
Monochrome (A4 / 8.5 x 11) Color (A4 / 8.5 x 11)
Copy Single: 50-sheet/min. (600 x 400 dpi, 1bit)
36-sheet/min. (600 x 600 dpi, 1 bit)
Duplex: 16-page/min. (600 x 400 dpi, 1bit)
14-page/min. (600 x 600 dpi, 1bit)
Single: 36-sheet/min. (600 x 600 dpi, 4 bit)
Duplex: 14-page/min. (600 x 600 dpi, 4 bit)
FAX / Internet FAX Single: 50-sheet/min. (200 x 200 dpi, 1 bit)
Duplex: 16-page/min. (200 x 200 dpi, 1 bit)
N/A
Scanner Single: 50-sheet/min. (200 x 200 dpi, 1 bit)
Duplex: 16-page/min. (200 x 200 dpi, 1 bit)
Single: 50-sheet/min. (200 x 200 dpi, 8 bit)
Duplex: 16-page/min. (200 x 200 dpi, 8 bit)
Detection Yes
Paper detection size
(Platen/RSPF)
Auto detection (Switching one type of detection unit)
RSPF
Inch-1 11 x 17, 8.5 x 14, 8.5 x 11, 8.5 x 11R, 5.5 x 8.5, A3, A4
Inch-2 11 x 17, 8.5 x 13, 8.5 x 11, 8.5 x 11R, 5.5 x 8.5, A3, A4
Inch-3 11 x 17, 8.5 x 13.4, 8.5 x 11, 8.5 x 11R, 5.5 x 8.5, A3, A4
AB-1 A3, B4, A4, A4R, B5, B5R, A5, 11 x 17, 8.5 x 14, 8.5 x 11
AB-2 A3, B4, A4, A4R, B5, B5R, A5, 11 x 17, 8.5 x 13, 8.5 x 11
AB-3 8K, 16K, 16KR, A3, B4, A4, A4R, A5, 11 x 17, 8.5 x 13, 8.5 x 11
AB-4 A3, B4, A4, A4R, B5, B5R, A5, 11 x 17, 8.5 x 13.4, 8.5 x 11
AB-5 A3, B4, A4, A4R, B5, B5R, A5, 11 x 17, 8.5 x 13.5, 8.5 x 11
