Sharp MX-4100N Service Manual

MX-5001N MAINTENANCE 8 – 4
2. Details
A. Photoconductor section
✕: Check (Clean, replace, or adjust according to necessity.) {: Clean S: Replace U: Adjust ✩: Lubricate
Color items
Monochrome items
No. Part name
When
calling
100
k
200
k
300
k
400
k
500
k
600
k
700
k
800
k
900
k
1000
k
1100
k
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
2 Drum Supply - SSSSSSSSS S S
3 MC unit { SSSSSSSSS S S(P/G No.: [24]-2)
4 Toner reception seal Mechanical
parts
- ✕✕✕✕✕✕✕✕✕ ✕ ✕
5 Side seal F/R - ✕✕✕✕✕✕✕✕✕ ✕ ✕
6 Cleaner blade Supply - SSSSSSSSS S S(P/G No.: [24]-14)
7 MC cleaner roller Mechanical
parts
- SSSSSSSSS S S(P/G No.: [2]-68)
No. Part name
When
calling
150
k
300
k
450
k
600
k
750
k
900
k
1050
k
1200
k
1350
k
1500
k
1650
k
Remark/Refer to the
Parts Guide.
Block/Item No.
(Only the replacement
parts are described.)
1 Waste toner box Mechanical
parts
✕ ✕✕✕✕✕✕✕✕✕✕✕
2 Drum Supply - SSSSSSSSSSS
3 MC unit { SSSSSSSSSSS(P/G No.: [24]-2)
4 Toner reception seal Mechanical
parts
- ✕✕✕✕✕✕✕✕✕✕✕
5 Side seal F/R - ✕✕✕✕✕✕✕✕✕✕✕
6 Cleaner blade Supply - SSSSSSSSSSS(P/G No.: [24]-14)
7 MC cleaner roller Mechanical
parts
- SSSSSSSSSSS(P/G No.: [2]-68)
1
2
6
4
3
7
5
5
7
