Sharp MX-4100N - Page 191

MX-5001N SIMULATION 6 – 44
30
30-1
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and the detectors in other than the
paper feed section and the control circuits.
Section
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The sensors and the detectors which are turned ON are high-
lighted.
30-2
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the sen-
sors and the detectors in the paper feed
section and the control circuits.
Section
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The sensors and the detectors which are turned ON are high-
lighted.
33
33-1
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the card
reader sensor and the control circuit.
Section
Operation/Procedure
The operating conditions of the sensors and detectors are dis-
played.
The sensors and the detectors which are turned ON are high-
lighted.
PPD1 Resist pre-detection
PPD2 Resist detection
POD1 Fusing rear detection
POD2 Main unit paper exit detection
POD3 Right tray paper exit detection
TFD2 Paper exit full detection
TFD3 Main unit right tray paper exit full detection
HPOS Shifter home detection
DSW_R Right door open/close detection
DSW_C Tray 1 transport cover open/close detection
DSW_F Front cover open/close detection
DHPD_K K phase detection
DHPD_C
(50-sheet machine only)
C phase detection
DHPD_M
(50-sheet machine only)
M phase detection
DHPD_Y
(50-sheet machine only)
Y phase detection
DHPD_CL
(41-sheet machine only)
CL phase detection
1TNFD Waste toner full detection
HLPCD Fusing roller pressure release detection
1TUD_CL Primary transport belt separation CL detection
1TUD_K Primary transport belt separation BK detection
1
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
0$,181,76(1625&+(&.





33'
33' 32'
32'
32' 7)'
7)'
+326
'6:B5
'6:B& '6:B)
'+3'B.
'+
78'B.
3'B&/
71)' +/3&'
78'B&/
CPFD1 Tray 1 transport detection
CLUD1 Tray 1 upper limit detection
CPED1 Tray 1 paper empty detection
CSPD1 Tray 1 paper remaining quantity detection
CSS11 Tray 1 rear edge detection 1
CSS12 Tray 1 rear edge detection 2
CSS13 Tray 1 rear edge detection 3
CSS14 Tray 1 rear edge detection 4
CPFD2 Tray 2 transport detection
CLUD2 Tray 2 upper limit detection
CPED2 Tray 2 paper YES/NO detection
CSPD2 Tray 2 paper remaining detection
CSS21 Tray 2 rear edge detection 1
CSS22 Tray 2 rear edge detection 2
CSS23 Tray 2 rear edge detection 3
CSS24 Tray 2 rear edge detection 4
MPFD Manual feed paper entry detection
MPLD Manual feed paper length detection
MTOP1 Manual feed tray retraction detection
MTOP2 Manual feed tray extension detection
MPED Manual feed paper empty detection
CARD Card Yes/No detection
DATA Card number signal detection
CLOCK Reference clock signal detection
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
75$<6(1625&+(&.0$,1





&3)' &/8' &3(' &63'
&66 &66 &66 &66
&3)' &/8' &3(' &63'
&66 &66 &66 &66
03('
03)' 03/' 0723 0723
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
&$5'5($'(56(1625&+(&.





&$5'
'$7$ &/2&.
