MX-5001N SIMULATION 6 – 46
41-2
Purpose
Adjustment
Function (Purpose)
Used to adjust the document size sensor
detection level.
Section
Operation/Procedure
1) Open the document cover, and press [EXECUTE] key without
place a document on the document table.
The sensor level without document is recognized.
2) Set A3 (11” x 17") paper on the document table, and press
[EXECUTE] key.
The sensor level when detecting the document is displayed.
When the above operation is normally completed, it is displayed.
41-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the docu-
ment size sensor and the control circuit.
Section
Operation/Procedure
The detection output level (A/D value) of OCSW and the document
sensor (PD1 - PD7) is displayed in real time.
The light receiving range of PD1 - PD7 is 1 - 255. (Default: 128)
43
43-1
Purpose
Setting
Function (Purpose)
Used to set the fusing temperature in each
mode.
Section
Operation/Procedure
1) Select an item to be set with [↑] [↓] keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
[41-sheet machine]
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
'2&80(176,=(3+2726(16256(783


(;(&87(
Item/Display Content Detection level range
OCSW Original cover SW 0-1 ("1" to Close)
PD1 Document detection 1 0 - 255
PD2 Document detection 2 0 - 255
PD3 Document detection 3 0 - 255
PD4 Document detection 4 0 - 255
PD5 Document detection 5 0 - 255
PD6 Document detection 6 0 - 255
PD7 Document detection 7 0 - 255
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
3'6(1625',63/$<



2&6:
3'>@
3'>@
3'>@
3'>@
3'>@
3'>@
3'>@
1
Item/Display Content
Setting
range
Default value
Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
SW-A SW-B SW-A SW-B SW-A SW-B
A HL_UM READY Ready standby TH_UM set value 70 - 230 170 180 175 180 175 180 {
B HL_LM READY Ready standby TH_LM set value 30 - 200 100 115 110 115 110 115 {
C HL_E READY Ready standby TH_E set value 70 - 230 170 185 175 185 185 185 {
D HL_UM PLAIN PAPER BW Black-White plain paper TH_UM set value 70 - 230 175 180 175 180 180 185 {
E HL_LM PLAIN PAPER BW Black-White plain paper TH_LM set value 30 - 200 105 130 120 130 130 130 {
F HL_E PLAIN PAPER BW Black-White plain paper TH_E set value 70 - 230 225 225 225 225 225 225 {
G HL_UM PLAIN PAPER CL Color plain paper TH_UM set value 70 - 230 175 180 175 180 180 185 {
H HL_LM PLAIN PAPER CL Color plain paper TH_LM set value 30 - 200 110 130 120 130 130 130 {
I HL_E PLAIN PAPER CL Color plain paper TH_E set value 70 - 230 225 225 225 225 225 225 {
J WARMUP FUMON HL_E T Fusing motor pre-rotation start TH_E set
value
30 - 200 150 150 150 150 150 150 {
K WARMUP FUMOFF HL_LM T Fusing motor pre-rotation end TH_LM set
value
30 - 200303030303030 {
L WARM UP END TIME Warm-up complete time 30 - 255 115 180 115 180 115 180 {
: Oct. 24 2008
