MX-5001N SIMULATION 6 – 51
43-20
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environmental correction
under low temperature and low humidity (L/
L) for the fusing temperature setting (SIM
43-1) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with [↑] [↓] keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2) is saved.
Correction value: -49 - +49, 1 Count = 1°C Change
[41-sheet machine]
Correction
value
-49 -25 -5 0 5 25 49
Input value 1 25 45 50 55 75 99
1
Item/Display Content
Setting
range
Default value Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
A HL_UM READY LL Correction value for TH_UM set value in Ready standby
under LL environment
1 - 99 55 55 55 {
B HL_LM READY LL Correction value for TH_LM set value in Ready standby
under LL environment
1 - 99 55 55 55 {
C HL_E READY LL Correction value for TH_E set value in Ready standby
under LL environment
1 - 99 55 55 55 {
D HL_UM PLAIN BW LL Correction value for Black-White plain paper TH_UM set
value under LL environment
1 - 99 55 55 55 {
E HL_LM PLAIN BW LL Correction value for Black-White plain paper TH_LM set
value under LL environment
1 - 99 55 55 55 {
F HL_E PLAIN BW LL Correction value for Black-White plain paper TH_E set
value under LL environment
1 - 99 50 50 50 {
G HL_UM PLAIN CL LL Correction value for Color plain paper TH_UM set value
under LL environment
1 - 99 55 55 55 {
H HL_LM PLAIN CL LL Correction value for Color plain paper TH_LM set value
under LL environment
1 - 99 55 55 55 {
I HL_E PLAIN CL LL Correction value for Color plain paper TH_E set value
under LL environment
1 - 99 50 50 50 {
J WARMUP FUMON HL_E T LL Correction value for fusing motor pre-rotation start TH_E
set value under LL environment
1 - 99 45 45 45 –
K WARMUP FUMOFF T LL Fusing motor prior rotation completion time under LL
environment
1 - 99 50 50 50 –
L WARMUP END TIME LL Correction value for warm-up complete time under LL
environment
1 - 99 80 80 80 –
M HL_UM HEAVY LL Correction value for heavy paper TH_UM set value under
LL environment
1 - 99 55 55 55 –
N HL_LM HEAVY LL Correction value for heavy paper TH_LM set value under
LL environment
1 - 99 55 55 55 –
O HL_E HEAVY LL Correction value for heavy paper TH_E set value under LL
environment
1 - 99 50 50 50 –
P HL_UM OHP LL Correction value for OHP TH_UM set value under LL
environment
1 - 99 55 55 55 –
Q HL_LM OHP LL Correction value for OHP TH_LM set value under LL
environment
1 - 99 55 55 55 –
R HL_E OHP LL Correction value for OHP TH_E set value under LL
environment
1 - 99 50 50 50 –
S HL_UM ENVELOPE LL Correction value for envelope TH_UM set value under LL
environment
1 - 99 55 55 55 –
T HL_LM ENVELOPE LL Correction value for envelope TH_LM set value under LL
environment
1 - 99 55 55 55 –
U HL_E ENVELOPE LL Correction value for envelope TH_E set value under LL
environment
1 - 99 50 50 50 –
V HL_UM GLOSS LL Correction value for glossy paper TH_UM set value under
LL environment
1 - 99 55 55 55 –
W HL_LM GLOSS LL Correction value for glossy paper TH_LM set value under
LL environment
1 - 99 55 55 55 –
X HL_E GLOSS LL Correction value for glossy paper TH_E set value under LL
environment
1 - 99 50 50 50 –
Y HL_UM E-STAR LL Correction value for preheating TH_UM set value under LL
environment
1 - 99 55 55 55 –
Z HL_E E-STAR LL Correction value for preheating TH_E set value under LL
environment
1 - 99 55 55 55 –
AA PRE-JOB LL Correction value for resetting from preheating
TH_UM+TH_E set value under LL environment
1 - 99 55 55 55 –
