MX-5001N SIMULATION 6 – 68
44-16
Purpose
Operation data display
Function (Purpose)
Used to display the toner density control
data.
Section
Developing system
Operation/Procedure
1) Select a target color with [K] [C] [M] [Y] key.
The toner density control data are displayed.
Item/
Display
Content
Setting
range
Default
value
TONER
DEN_LT (M)
The current toner density sensor
output value (final value) at the
medium speed
1 - 255 129
TONER
DEN_ST (M)
The current toner density reference
value display (including all the
correction values) at the medium
speed
128
TONER
DEN_LT (L)
The current toner density sensor
output value (final value) at the low
speed
129
TONER
DEN_ST (L)
The current toner density reference
value display (including all the
correction values) at the low speed
128
Item/Display Content
Setting
range
Default
value
AUTO DEVE
(M)
Auto
development
adjustment
value
(At the
medium
speed)
Sensor output value
after completion of
SIM25-02
(at the medium
speed)
1 - 255 128
ALL (M) All the
correction
reference
values
(At the
medium
speed)
Correction reference
value which
calculated all the
correction values for
the auto
development
adjustment value
(at the medium
speed)
AUTO DEVE
(L)
Auto
development
adjustment
value
(At the low
speed)
Sensor output value
after completion of
SIM25-02
(at the low speed)
ALL (L) All the
correction
reference
values
(At the low
speed)
Correction reference
value which
calculated all the
correction values for
the auto
development
adjustment value
(at the low speed)
