Sharp MX-4100N - Page 227

MX-5001N SIMULATION 6 – 80
46-19
Purpose
Setting
Function (Purpose)
Used to set the operating conditions for the
density scanning (exposure) of mono-
chrome auto copy mode documents.
Section
Operation/Procedure
Select an item to be set with touch panel.
When an item is selected, it is highlighted and the setting change is
saved.
NOTE:
46-21
Purpose
Adjustment
Function (Purpose)
Copy color balance adjustment (Manual
adjustment)
Section
Operation/Procedure
1) Select an adjustment target color with [K][C][M][Y] keys on the
touch panel.
2) Select an adjustment target item with [↑] [↓] key on the touch
panel.
3) Enter the set value with 10-key.
* When the U V key is pressed, the setting value of each
item can be changed with 1up (1down) collectively.
4) Press [OK] key. (The set value is saved.)
When the adjustment value is increased, the image density is
increased, and vice versa.
When [EXECUTE] key is pressed, the check pattern in printed in
the color balance and density corresponding to the adjustment
value.
Item/Display Content Set value
Default
value
AE_MODE Auto exposure mode MODE1,
MODE2
MODE1
AE_STOP_COPY Auto B/W exposure
Stop (for copy)
REALTIME/
STOP/
PRESCAN
STOP
AE_STOP_FAX Auto B/W exposure
Stop (for FAX)
ON/OFF ON
AE_STOP_SCAN Auto B/W exposure
Stop (for scanner)
REALTIME/
STOP/
PRESCAN
STOP
AE_FILTER Auto exposure filter
setting
SOFT NORMAL
NORMAL
SHARP
AE_WIDTH AE exposure width FULL/PART FULL
MODE 1 High gamma (high contrast images)
MODE 2 Normal gamma
STOP The image density in 3 - 7mm area at the lead edge is
scanned, and the output image density is determined
according to the scanned density. (The output image
density is even for all the surface.)
REALTIME The densities of the document width are scanned
sequentially, and the output image density is
determined according to the density in each area of
document. (The output image density may not be
even for all the surface.)
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
(1*,1(*5$<%$/$1&(0$18$5/$'-8670(17>$//%:@3*



$˖
˷˹
˖32,17
$˖
˖32,17
%˖
˖32,17
&˖
˖32,17
'˖
˖32,17
)˖
˖32,17
(˖
˖32,17
*˖
˖32,17
+˖
˖32,17
,˖
˖32,17
-˖
˖32,17
.˖
˖32,17
/˖
2.
(;(&87(
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
(;32685(02'(6(783%:$(





02'( 02'(
$(B02'( ˖
5($/7,0( 35(6&$16723
$(B6723B&23< ˖
2)) 21
$(B6723B)$; ˖
5($/7,0( 35(6&$16723
$(B6723B6&$1 ˖
62)7 6+$531250$/
$(B),/7(5 ˖
)8// 3$57
$(B:,'7+ ˖
PRESCAN The densities of the all surface of document are
scanned sequentially, and the output image density is
determined according to the average of the scanned
densities. (The output image density is even for all the
surface.)
AE WIDTH FULL The document density scan area in the monochrome
auto mode is 3 - 7mm at the document lead edge x
the document width. This is not related to the prescan
mode.
AE WIDTH PART The document density scan area in the monochrome
auto mode is 3 - 7mm at the document lead edge x
100mm width. This is not related to the PRESCAN
mode.
Item/Display
Density level
(Point)
Setting range
Default
value
A POINT1 Point 1 245 - 755 500
B POINT2 Point 2 245 - 755 500
C POINT3 Point 3 245 - 755 500
D POINT4 Point 4 245 - 755 500
E POINT5 Point 5 245 - 755 500
F POINT6 Point 6 245 - 755 500
G POINT7 Point 7 245 - 755 500
H POINT8 Point 8 245 - 755 500
I POINT9 Point 9 245 - 755 500
J POINT10 Point 10 245 - 755 500
K POINT11 Point 11 245 - 755 500
L POINT12 Point 12 245 - 755 500
M POINT13 Point 13 245 - 755 500
N POINT14 Point 14 245 - 755 500
O POINT15 Point 15 245 - 755 500
P POINT16 Point 16 245 - 755 500
Q POINT17 Point 17 245 - 755 500
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
(1*,1(&2/25%$/$1&(0$18$/$'-8670(17>$//&2/25@



$˖
˷˹
˖32,17
$˖
˖32,17
%˖
˖32,17
&˖
˖32,17
'˖
˖32,17
)˖
˖32,17
(˖
˖32,17
*˖
˖32,17
+˖
˖32,17
,˖
˖32,17
-˖
˖32,17
.˖
˖32,17
/˖
2.(;(&87(
. & 0 <
