MX-5001N SIMULATION 6 – 101
All adjustment items: 1 step = 0.1mm change
Items C - H are linked with items C - H of SIM50-06.
50-10
Purpose
Adjustment
Function (Purpose)
Used to adjust the black print image magni-
fication ratio and the off-center position.
(The adjustment is made separately for
each paper feed section.)
Section
Operation/Procedure
1) Select an adjustment target item with [↑] [↓] key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [EXECUTE] key. (The set value is saved.)
Item A: When the set value is increased, the BK image magnifica-
tion ratio in the main scanning direction is increased. When the set
value is decreased, the image magnification ratio is decreased.
Item B - H: When the adjustment value is increased, it is shifted to
the front frame side. When the adjustment value is decreased, it is
shifted to the rear frame side.
All adjustment items: 1 step = 0.1mm change
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
/($'('*($'-8670(1763)&$/&



$˖
˷˹
˖/
$˖
˖/
%˖
˖/($'B('*(6,'(
&˖
˖)5217B5($56,'(
'˖
˖/($'B('*(6,'(
)˖
˖75$,/B('*(6,'(
(˖
˖)5217B5($56,'(
*˖
˖75$,/B('*(6,'(
+˖
(;(&87(
Item/Display Content Setting range
Default
value
NOTE
A BK-MAG Main scan print magnification ratio BK 60 - 140 100 Adjustment Item List
B MAIN-MFT Print off center adjustment value
(Manual paper feed)
1 - 99 50
C MAIN-CS1 Print off center adjustment value (Tray 1) 1 - 99 50
D MAIN-CS2 Print off center adjustment value (Tray 2) 1 - 99 50
E MAIN-CS3 Print off center adjustment value (Tray 3) 1 - 99 50
F MAIN-CS4 Print off center adjustment value (Tray 4) 1 - 99 50
G MAIN-LCC Print off center adjustment value
(Large capacity tray)
1 - 99 50
H MAIN-ADU Print off center adjustment value (Duplex)
(NOTE) If the adjustment items A - G are
not properly adjusted, this adjustment
cannot be executed properly.
1 - 99 50 Adjustment Item List
I SUB-MFT Resist motor ON
timing adjustment
Manual paper feed 1 - 99 50
J SUB-CS12 Standard cassette 1 - 99 50
K SUB-CS34 DESK 1 - 99 50
L SUB-LCC LCC 1 - 99 50
M SUB-ADU ADU 1 - 99 50
N MULTI COUNT Number of print 1 - 999 1 Adjustment pattern print conditions setting
O PAPER MFT Tray selection Manual paper feed 1 - 6 1 2 (CS1)
CS1 Tray 1 2
CS2 Tray 2 3
CS3 Tray 3 4
CS4 Tray 4 5
LCC LCC 6
P DUPLEX YES Duplex print
selection
Yes 0 - 1 0 1 (NO)
NO No 1
ǂǂǂ6,08/$7,21ǂǂ127(67
3$3(5&(17(52))6(76(783

$˖
˷
˹
˖%.0$*
$˖
˖0$,10)7
%˖
˖0$,1&6
&˖
˖0$,1&6
'˖
˖0$,1&6
)˖
˖0$,1&6
(˖
˖0$,1/&&
*˖
˖0$,1$'8
+˖
˖68%0)7
,˖

˖68%&6
-˖
˖68%&6
.˖
˖

68%/&&
/˖
2.


&/26(
(;(&87(
