MX-5001N ADJUSTMENTS 5 – 55
4) When [DSPF] button is pressed, it is highlighted, and the color
automatic adjustment execution screen is displayed.
5) Press [EXECUTE] button and it is highlighted and the color
auto adjustment is executed.
* When [EXECUTE] button is pressed during the automatic
adjustment, the automatic adjustment is interrupted.
6) After normal completion, the result of calculation is displayed
in the initial screen.
* When an error occurs in execution, the following screen is dis-
played.
When [CA] key is pressed, the simulation is terminated. When
[SYSTEM SETTINGS] key is pressed, the display returns to the
sub number entry screen.
* When an error occurs in the automatic adjustment, all the error
patch numbers are displayed.
When [RESULT] button is pressed, the display returns to the ini-
tial screen. (The previous value is displayed)
* When the operation is completed normally, "COMPLETE" is dis-
played. When [RESULT] button is pressed, the display returns to
the initial screen. (The calculation result of normal completion is
displayed.)
20-A (3)
Shading adjustment (DSPF mode)
1) Open the lower door, and insert the white reference sheet
DSPF (PSHEP5668FCZZ). Close the lower door.
* When inserting the white reference sheet DSPF, insert it
straight along the rear edge frame so that the rear edge of
the white reference sheet DSPF comes at the root of the
actuator as shown in the mark {.
7(67
6&$11(5&2/25%$/$1&($872$'-8670(17
6(77+(&+$57213/$7(1$1'728&+>(;(&87(@
ǂǂǂ6,08/$7,21ǂǂ12
7(67
6&$11(5&2/25%$/$1&($872$'-8670(17
12:&+$573$7&+5($',1*
ǂǂǂ6,08/$7,21ǂǂ12
7(67
6&$11(5&2/25%$/$1&($872$'-8670(17
6&$11(502725,61275($'<
ǂǂǂ6,08/$7,21ǂǂ12
7(67
6&$11(5&2/25%$/$1&($872$'-8670(17
6$035,1*'$7$81),7
3/($6(&+(&.7+(&+$57$1'3/$7(1*/$66
7(67
6&$11(5&2/25%$/$1&($872$'-8670(17
