Sharp MX-4500N - Page 140

MX3500N SIMULATION 7 – 32
(*): AR-C260 series VENDOR MODE is supported.
Operation 1: Wait for auto clear setting time. Default, 60sec. Can
be changed by the system setting.
Operation 2: Auto clear is not made.
Operation 3: Setting is immediately cleared. The display returns to
the initial screen.
26-5
Purpose
Setting
Function (Purpose)
Used to set the count mode of the total
counter and the maintenance counter.
Section
—
Item
Counter
Operation/Procedure
1) Select the set item with [↑] [↓] buttons.
2) Enter the set value with 10-key.
3) Press [OK] button.
The set content in step 2) is saved. (Count-up number for A3
paper is 1 or 2.)
* 1 = Count up by 1
2 = Count up by 2
26-6
Purpose
Setting
Function (Purpose)
Used to set the specifications (paper, fixed
magnification ratio, etc.) of the destination.
Section
—
Item
Specifications (Destination)
Operation/Procedure
1) Select the set target with the button on the touch panel.
2) Press [EXECUTE] button.
The selected set content is saved.
26-10
Purpose
Setting
Function (Purpose)
Used to set the trial mode of the network
scanner.
Section
—
Item
Operation
Operation/Procedure
1) Enter the set value with 10-key.
* Press [C] key to clear the entered value.
2) When [OK] button is pressed, the current entered value is
saved to EEPROM and RAM.
* When [COLOR], or [BLACK] key is pressed, the value is
saved to EEPROM and RAM.
<Setting range and default value of each set value>
COUNTUP
TIMING1
FUSER_IN The charging timing is when
passing the sensor paper lead
edge after fusing.
EXIT_OUT
FUSER_OUT The charging timing is when
passing the sensor paper rear
edge after fusing.
EXIT_OUT The charging timing is when
passing the (machine, right)
tray/after-process unit paper
exit sensor paper rear edge.
Diagnosis
setting
The
specified
quantity is
completed.
Remainder
of money
left.
Insufficient money during
copy job
The
specified
quantity is
completed.
No
remainder
of money.
BLACK/
COLOR (No
remainder
of money)
COLOR
(Remainder
of money
left)
Condition 1 Condition 2 Condition 3 Condition 4
MODE1 Operation 1 Operation 2 Operation 2 Operation 1
MODE2 Operation 1 Operation 1 Operation 2 Operation 1
MODE3 Operation 1 Operation 3 Operation 2 Operation 3
Item Display Content
Setting
range *
Default
A TOTAL (B/W) Total counter (BLACK) 1 to 2 2
B TOTAL (COL) Total counter (COLOR) 1 to 2 2
C MAINTENANCE
(B/W)
Maintenance counter
(BLACK)
1 to 2 2
D MAINTENANCE
(COL)
Maintenance counter
(COLOR)
1 to 2 2
E DEV (B/W) Developer counter
(BLACK)
1 to 2 2
F DEV (COL) Developer counter
(COLOR)
1 to 2 2
Item
Button
display
Content Default
0
SIMULATION  NO.26-03
TEST
AUDITOR SETUP
P10
BUILT-IN  AUDITOR
EC1
㧦
CLOSE
1/2
P OTHER
OUTSIDE  AUDITOR
㧦
 NONE
P VENDOR1
㧦
 ON
OFF
DOC  ADJ
㧦
 ON
OFF
PF  ADJ
㧦
MODE1
MODE3
VENDOR MODE
MODE2
U.S.A. United States of America
CANADA Canada
INCH Inch series, other destinations
JAPAN Japan
AB_B AB series (B5 detection), other destinations
EUROPE Europe
U.K. United Kingdom
AUS. Australia
AB_A AB series (A5 detection), other destinations
CHINA China
Item Display Content
Setting
range
Default
value
A TRIAL MODE
(0:YES 1:NO)
0 Trial mode setting 0 to 1 1
1 Trial mode cancel
0
A
:
A㧦 2
B㧦 2
C㧦 2
D㧦 2
㧧 TOTAL(B/W)
㧧 TOTAL(COL)
㧧 MAINTENANCE(B/W)
㧧 MAINTENANCE(COL)
SIMULATION  NO.26 㧙 05
A3(1117) COUNTUP
2
㨇 1㨪 2 㨉
OK
TEST
CLOSE
0
SIMULATI ON  NO.26-06
TEST
DISTINATION SETUP
EXECUTE
1/1
U.S.A
CANADA
INCH JAPAN
AB_B EUROPE
U.K.
AUS
AB_A CHIN
A
CLOSE
