MX3500N CONSUMABLE PARTS 3 – 2
D. Middle East/Africa/Israel/Philippines/Taiwan
*1: The toner life may vary depending on the document density and temperature and humidity.
2. Maintenance parts list
A. U.S.A/Canada/South and Central America/Asia/Middle East/Agencies
No. Item Content Life Model Name Remarks
1 Toner Cartridge (Black) Toner Cartridge (Black) with IC Chip
(Black toner : Net 880g)
x 1 36K *1 MX-45FTBA * Life: A4/Letter size
at Area Coverage 5%
(Reference: 30K for A4/Letter 6%)
2 Toner Cartridge (Cyan) Toner Cartridge (Cyan) with IC Chip
(Cyan toner : Net 352g)
x 1 15K *1 MX-27FTCA * Life: A4/Letter size
at Area Coverage 5%
3 Toner Cartridge (Magenta) Toner Cartridge (Magenta) with IC Chip
(Magenta toner : Net 352g)
x 1 15K *1 MX-27FTMA * Life: A4/Letter size
at Area Coverage 5%
4 Toner Cartridge (Yellow) Toner Cartridge (Yellow) with IC Chip
(Yellow toner : Net 352g)
x 1 15K *1 MX-27FTYA * Life: A4/Letter size
at Area Coverage 5%
5 Developer (Black) Developer (Black)
(Black developer : Net 270g)
x 1 150K MX-27FVBA
6 Developer
(Cyan/Magenta/Yellow)
Developer (Cyan/Magenta/Yellow)
(Cyan/Magenta/Yellow developer : Net 270g)
x 1 100K MX-27FVSA
7 Drum OPC Drum x 1 150K (Black)
100K (Color)
MX-27FRSA
8 Drum Unit Drum Unit (OPC Drum/Unit Parts included)
Color identification seal (Bk/C/M/Y) x 1 each
x 1
x 1
150K (Black)
100K (Color)
MX-27FUSA
No. Item Content Life Model name Remarks
1 Heat roller kit Upper heat roller x 1 300K MX-450HK
Fuser gear x 1
Upper separation pawl x 4
Upper separation pawl SP-N x 4
Upper thermistor sub x 1
Upper thermistor side x 1
Upper thermistor CJ x 1
Upper heat roller bearing x 2
Lower heat roller x 1
Lower heat roller bearing x 2
Lower separation pawl/spring x 4
Lower thermistor x 1
2 Primary transfer kit Intermediate transfer belt x 1 150K MX-450Y1
Primary transfer blade x 1
Primary transfer conductive collar x 4
PS paper dust removal cleaner x 1
Bearing x 4
3 Secondary transfer kit Secondary transfer belt x 1 300K MX-450Y2
Secondary transfer roller x 1
Secondary transfer idle gear x 1
Primary transfer roller x 4
Belt drive gear x 1
4 Filter kit Ozone filter x 1 150K MX-450FL For North America/South
and Central America
Paper exit filter x 2
Ozone filter x 1 150K MX-270FLN For Asia/Agencies
5 Web cleaning kit Web unit x 1 150K MX-450WC
Sub roller x 1
Sub roller bearing x 2
6 Waste toner box kit Waste toner box unit (with LSU cleaner x 3) x 1 40K MX-270HB Each color 5% coverage,
color ratios 43%
7 DV seal kit DV seal x 3 Black: 150K,
Color: 100K
MX-270DS
DV side seal F/R x 3
Toner filter x 3
8 Main charger kit Main charger unit x 1 Black: 150K,
Color: 100K
MX-270MK
Drum cleaning blade x 1
9 Staple cartridge Staple cartridge x 3 5000 times x 3 AR-SC2 For saddle finisher
(MX-FNX2)
10 Staple cartridge Staple cartridge x 3 5000 times x 3 MX-SCX1 For inner finisher
(MX-FNX1)
11 Primary transfer belt unit Primary transfer belt unit (For service rotation) x 1 — MX-450U1
12 Secondary transfer belt unit Secondary transfer belt unit (For service rotation) x 1 — MX-450U2
13 Fusing unit Fusing unit (For service rotation) (Heater lamp 120V) x 1 — MX-450FU1
Fusing unit (For service rotation) (Heater lamp 230V) x 1 — MX-450FU
5
7
7
1
: Jan. 15 2006, : Jul. 15 2006, : Feb. 15 2007
1 5
7
To Next Page
