MX3500N SIMULATION 7 – 36
26-53
Purpose
Setting
Function (Purpose)
Used to set YES/NO of the auto color cali-
bration.
Section
—
Item
—
Operation/Procedure
1) Enter the set value with 10-key.
* Press [C] key to clear the entered value.
2) When [OK] button is pressed, the current set value is saved to
EEPROM and RAM.
* When [COLOR], or [BLACK] key is pressed, the current set
value is saved to EEPROM and RAM.
<Setting range and default value of each set value>
26-54
Purpose
Setting
Function (Purpose)
Used to set the printer calibration YES/NO.
Section
Printer
Item
Operation
Operation/Procedure
1) Enter the set value with 10-key.
* Press [C] key to clear the entered value.
2) When [OK] button is pressed, and the current set value is
saved to EEPROM and RAM.
After completion of setting, [OK] button returns to the normal
display.
* When [COLOR], or [BLACK] key is pressed, the current set
value is saved to EEPROM and RAM.
<Setting range and default value of each value>
26-65
Purpose
Setting
Function (Purpose)
Used to set the finisher alarm mode.
Section
—
Item
Specifications
Operation/Procedure
1) When the machine enters Simulation 26-65, the following
screen is displayed.
* The current set value is highlighted.
2) When the set value button of an item to be changed is
pressed, it is highlighted and the setting is saved to EEPROM
and RAM.
* Only one can be selected for each item.
<Item description>
<LIMIT SHEETS>
* Valid only when the 1K finisher is installed.
[Target paper size]
Staplable S-size paper described on the product specifications
A4, A4R, B5, B5R, 8.5 x 11, 8.5 x 11R, 16K, 16KR
* 25 sheets for L-size paper (A3, B4, 11 x 17, 8.5 x 14, 8.5 x 13,
8K) regardless of setting
* 25 sheets for mixed loading of a same width regardless of setting
26-67
Purpose
Setting
Function (Purpose)
Used to set the summer time (switching
timing to the summer time and the adjust-
ment time (shift amount)) and the time zone
(for switching to the summer time and the
difference between the local time and GMT
(UTC) for synchronization with the internet
time server).
Section
—
Item
Specifications
Operation/Procedure
1) Select a mode to be set. ([SUMMER TIME] is selected in this
example.)
* When [TIME ZONE] or [SUMMER TIME] button is pressed,
it is highlighted and item of the selected button is displayed.
* Only one can be selected, and the selected button is high-
lighted.
In the default display, [TIME ZONE] is selected.
2) Change the set item with [↑] and [↓] buttons.
The highlighted section of the set value is switched and the
value is displayed in the setting area.
Item Display Content
Setting
range
Default
value
A (1:YES 0:NO) 1 ACC YES 0 to 1 1
0 ACC NO
Item Display Content
Setting
range
Default
value
A (1:YES 0:NO) 1 ACC YES 0 – 1 1
0 ACC NO
0
A
:
A㧦 1
㧧 (1:YES 0:NO)
SIMULATION  NO.26-53
ENABLING OF AUTOMATIC COLOR CALIBRATION
1
㨇 0㨪 1 㨉
OK
TEST
CLOSE
0
A
:
A㧦 1
㧧 (1:YES 0:NO)
SIMULATION  NO.26 㧙 54
ENABLING OF AUTOMATIC COLOR CALIBRATION OF PRINTER
1
㨇 0㨪 1 㨉
OK
TEST
CLOSE
Item
Set
value
Content
Setting
range
Default
value
LIMIT
SHEETS
30 Staple limit sheets: 30 sheets 30 or 50 30
50 Staple limit sheets: 50 sheets
LIMIT
COPIES
ON Staple limit copies ON ON or OFF ON
OFF Staple limit copies OFF
SIMULATION NO.26-65
TEST
FINISHER ALARM MODE SETUP (STAPLE LIMIT)
30
50
LIMIT SHEETS :
1/1
0
ON
OFF
LIMIT COPIES :
CLOSE
