MX3500N DEVELOPING SECTION K – 5
g. Toner filter
1) Remove the developing unit.
2) Remove the toner filter cover and the toner filter.
4. Maintenance
: Check (Clean, replace, or adjust according to necessity.) {: Clean : Replace : Adjust ✩: Lubricate : Shift the position.
No. Part name
Monochrome
supply/
Mechanical parts When
calling
150
K
300
K
450
K
600
K
750
K
900
K
1050
K
1200
K
1350
K
1500
K
1650
K
1800
K
Remark/Refer to
the Parts Guide.
Block/Item No.
(Only the
replacement parts
are described.)
Color supply
100
K
200
K
300
K
400
K
500
K
600
K
1 Developer (BK) Monochrome
supply
2DV seal (BK) (P/G No.: [22]-42)
3 DV side seal F
(BK)
(P/G No.: [22]-26)
4 DV side seal R
(BK)
(P/G No.: [22]-15)
5 Toner filter (P/G No.: [21]-37)
6 Developer (C) Color supply
7 Developer (M)
8 Developer (Y)
9DV seal (C) (P/G No.: [22]-42)
10 DV side seal F/R
(C)
(P/G No.: [22]-26,
[22]-15)
11 Toner filter (P/G No.: [21]-37)
12 Bias terminal/
connector
Mechanical parts
1,6,7,8
2,9
12
12
3,10
4,10
5,11
12
