MX3500N SPECIFICATIONS 2 – 2
(10) Power source
(11) Power consumption
*1: Heater is OFF when power source ON.
(12) Noise
(13) Dimensions
(14) Weight
(15) Dimensions occupied by Machine (with Multi
Manual/Exit tray extended)
B. Paper feed unit/Transport/Paper exit secton
(1) Machine paper feed tray
(2) Paper feed tray 1/tray 2
(3) Manual feed tray (Bypass tray)
(4) Double-sided
(5) Paper exit tray (Center tray)
100V type 200V type
Voltage / Current 100 – 127V 12A 220 – 240V 8A
Frequency 50/60Hz
Power source
code
Fixed type (direct) Inlet type
Power switch 2 switches (Primary switch: in the front cover;
Seconday switch: the operation panel)
100V type 200V type
Maximum rated power
consumption
1.44kW 1.84kW
In action B/W : 63dB or less
Color : 63dB or less
Standby B/W : 55dB or less
MX-3500N/MX-4500N MX-3501N/MX-4501N
Outer dimensions
(W x D x H)
645 x 670 x 950mm
(25 25/64 x 26 3/8 x
37 26/64 inch)
645 x 670 x 960mm
25 25/64 x 26 3/8 x
37 51/64 inch)
Footprint (W x D) 645 x 670mm
(25 25/64 x 26 3/8 inch)
645 x 670mm
(25 25/64 x 26 3/8 inch)
MX-3500N/MX-4500N MX-3501N/MX-4501N
Main unit Approx. 114kg (251lbs) Approx.123kg (271lbs)
Main unit +
Developer +
Toner cartridge
Approx. 119kg (262lbs) Approx.128kg (282lbs)
MX-3500N/MX-4500N MX-3501N/MX-4501N
W1075 x D 670mm (W42 21/64 x D26 3/8 inch)
Form Standard: Double feeder tray + multi manual
Maximum: Fourfold feeder tray + multi manual +
large capacity feeder cassette
Feeding method Feeding from the upper section with front loading
Heater (Engine part) Service parts
Feeding method Feeding from the upper section with front loading
Heater (Engine part) Service parts
Paper size A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR
11 x 17, 8.5 x 14, 8.5 x 13, 8.5 x 11,
8.5 x 11R, 7.25 x 10.5R, 5.5 x 8.5R
Changing of paper
size
Guide adjustment by users
Paper type setting Yes
Default paper size
setting
Shipped with max. width of paper guide
Feedable paper
type/weight
Plain paper: 60-105g/m
2
(16-28 lbs)
Paper capacity Standard paper: 500 sheets (80g/m
2
, 21lbs)
Paper Type Plain paper, pre-printed paper (not including
backing paper), recycled paper, letter head, pre-
punched paper, colored paper
* Users can set up all of these paper types.
Paper size detection
* About A5R, 5.5 x
8.5R, 8K, 16K,
16KR, manual
setting.
A3, B4, A4, A4R, B5, B5R, A5R, 8.5 x 13
11 x 17, 8.5 x 14, 8.5 x 11, 8.5 x 11R, 7.25 x 10.5R
Detection of
Remaining Paper
Level detection (4 levels: 100%, 67%, 33%, and
none)
Paper Size A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR
12 x 18, 11 x 17, 8.5 x 14, 8.5 x 13, 8.5 x 11, 8.5 x
11R, 7.25 x 10.5R, 5.5 x 8.5R
Envelope (Monarch / Com-10 / DL / C5 / Rectangle 3 /
Western 2 / Western 4)
Extra Size (Tab paper is limited to A4; tab width
12mm-20mm / 8.5 x 11; tab width 6.1-17mm)
Changing of
paper size
Guide adjustment by users
Paper type setting Yes
Feedable paper
type/weight
Thin paper: 55 – 59g/m
2
(15 – 16 lbs)
Plain paper: 60 – 105g/m
2
(16 – 28 lbs)
Heavy Paper: 106 – 209g/m
2
(28 – 56 lbs)
Envelope: 75 – 90g/m
2
(20 – 24 lbs)
OHP
Label paper
Tab paper
Gloss Paper
Paper capacity Standard paper: 100 sheets
Envelope: 20 sheets
OHP: 20 sheets
Heavy paper: 40 sheets
Tab paper: 20 sheets
Gloss paper: 20 sheets *
Other special paper: 1 sheet
* The gloss paper is sucked under a high
temperature environment to cause double feed or
misfeed. In such a case, manually supply paper
sheet by sheet (Select heavy paper).
Paper Type Plain paper, pre-printed paper (Excluding back print
paper), recycled paper, letter head, pre-punched
paper, colored paper, heavy paper, thin paper, label
paper, OHP, tab paper, envelope.
* Users can set up all of these paper types.
Paper size
detection
Auto Detect
Auto-AB
A3, B4, A4, A4R, B5, B5R, A5R, 8.5 x
13, Postcard, 8.5 x 11, 11 x 17
Auto Detect
Auto-Inch
12 x 18, 11 x 17, 8.5 x 14, 8.5 x 11,
8.5 x 11R, 5.5 x 8.5R, 7.25 x 10.5R,
A3, B4, A4, B5
For China A3, B4, A4, A4R, B5, B5R, A5R, 11 x
17, 8.5 x 14, 8.5 x 11, 8K, 16K
Detection of
remaining paper
yes or no only
Method Non-Stack
Paper size A3, B4, A4, A4R, B5, B5R, A5R, 8K, 16K, 16KR,
11 x 17, 8.5 x 14, 8.5 x 13, 8.5 x 11, 8.5 x 11R,
8.5 x 5.5R
Paper type Plain paper, pre-printed paper (not including
backing paper), recycled paper, letter head, pre-
punched paper, colored paper
Paper weight
(for duplex operation)
Plain paper: 60-105g/m
2
(16-28 lbs)
Heavy paper: 106-209g/m
2
(28-56 lbs)
Logo paper support For paper such as letterhead paper with front-
back attributes, the engine control must be cared
for printing side.
Exit location/method Face down in the main unit
Exit capacity 500 sheets (A4 or 8.5 x 11 (color recommended
paper))
Exit paper size/type All feedable paper except 12x18.
Exit paper detection No
Exit tray full
detection
Yes
Shifting function Yes
Rotation sort No
