1-88
BEFORE USING THE MACHINE
â–º
LOADING PAPER
HOW TO PLACE THE LONG PAPER GUIDE
The steps for attaching the optio
nal long paper feeding tray to the bypa
ss tray are explained belo
w.
1
Extend the auxiliary
guide of the long
paper feeding tray.
2
Pull out the exten
sion guide of the
bypass tray.
3
Attach the long paper feeding tray
onto the extension guide of the bypass
tray.
4
Replace the extens
ion guide of the
bypass tray.
90
92
