Sharp MX-B201D Technical Handy Guide

SHARP
INITIAL SETUP
5
DEVELOPER INSTALLATION
Sim 25-01 Developer Cycle/Stir (Once)
Toner Cartridge must be installed before execution.
PRODUCT ACTIVATION & FIRMWARE UPGRADE
Activation of Optional Product(s).
Sim 22-14 Check Firmware version(s):- Upgrade to latest version.
INITIAL SETUP
Sim 21-01 Maintenance Cycle Setting:- Set to 4 = 25K.
Sim 26-02 RSPF [MX-RP13] Installation:- 0 = None, 1 = Enable.
Sim 26-03 Second Cassette [MX-CS10] Installation:- 0 = None, 1 = Enable.
Sim 26-04 Duplex Mode Setting:- 0 = None, 1 = Enable.
Sim 26-06 Machine Destination:- AB Series(EX) = 1.
Set paper size by adjusting the guides in the cassette.
PRINT ENGINE IMAGE SKEW & OFF CENTRE
Sim 64-01 Image Writing (Skew) Adjustment:- Select 1 (Grid Pattern).
Sim 50-10 Image Off Centre Adjustment:- Check All Cassettes.
COPY IMAGE QUALITY
Check Image Quality (Copy Mode) – Density, Magnification, Lead Edge & Void.
If NG, perform the following adjustments as required:-
Sim 46-01 Copy Density Adjust. (300dpi).
Sim 46-02 Copy Density Adjust. (600dpi).
Sim 48-01 Magnification Adjustment (OC & SPF):-
Print Mode Lamp = Main Scan.
Scan Mode Lamp = Sub Scan.
Sim 50-01 Lead/Rear Edge, Loss & Void Adjust.
Sim 50-12 OC & SPF Off Centre Adjust.
Sim 41-06 Float Level Calibration [MX-RP13].
Sim 48-05 SPF Magnification Adjustment [MX-RP13].
