MAINTENANCE & CONSUMABLES
SHARP
8
Maintenance Schedule:
 : Clean  : Replace
Section
Parts
25K
50K
75K
100K
125K
Developing
Developer





DV blade





DV side seal (F/R)





Process Peripheral
Drum





Interval Checklist
25K
50K
Interval:
Process Section:
Replace Developer [MX-B20GV1]
X
Replace DV Blade
X
DV Side Seal F & R [PSHEZ0029QS11] & [PSEL-0096QSZZ]
Clean MC Grid & Transfer Corona Wire
Check & Clean DV Blade
Replace OPC Drum [AR-152DM]
Replace Drum Cleaner Blade [CCLEZ0013QS01]
Sim 24-06 Clear Developer Counter
Sim 24-07 Clear Drum Counter
Sim 20-01 Clear Maintenance Counter
Sim 25-01 Developer/Toner Stir (& Main Motor Check)
Paper Feed & Transport:
Check/Clean/Replace PF Rollers
Sim 24-01 Clear Jam Counter (if required).
Fuser Section:
Check/Clean Fuser Separation Pawls
Check/Clean Upper Thermistor
Document Feeder:
Check/Clean/ PF Rollers (replace when necessary)
Clean all RSPF/DSPF sensors.
General:
Clean all optics, CCD, and white reference plate.
Image Quality:
Sim 46-01 Adjust Copy Exposure Density (300dpi ).
Sim 46-02 Adjust Copy Exposure Density (600dpi)
