1 Top 30 5 m m (1 2 i n. )
2 Rear 100 mm (3.94 in.)
3 Right side 110 mm (4.33 in.)
4 Front 305 mm (12 in.)
Note: The minimum space needed in front of the printer is 75 mm (3 in.)
5 Left side 65 mm (2.56 in.)
Printer configurations
CAUTION—TIPPING HAZARD: Installing one or more options on your printer or MFP may require a
caster base, furniture, or other feature to prevent instability causing possible injury. For more information
on supported configurations, contact the place where you purchased the printer.
CAUTION—TIPPING HAZARD: To reduce the risk of equipment instability, load each tray separately.
Keep all other trays closed until needed.
You can configure your printer by adding optional 250‑ or 550‑sheet trays. For more information, see
“Installing
optional trays” on page 118.
1 Control panel
2 Standard bin
3 Controller board access cover
4 Standard 250‑sheet tray
5 Optional 250‑ or 550‑sheet tray
6 Multipurpose feeder
Learning about the printer 9
