MX-C250 SIMULATION 6 – 65
66
66-1
Purpose
Setting
Function (Purpose)
Used to display the FAX-related soft SW (2
- 150) on the LCD to allow changing the
soft SW while checking with the LCD.
Section
FAX
Operation/Procedure
1) Enter the [SW NO] with 10keys.
* When [C] key is pressed, the entered value of [SW NO] is
cleared.
2) Press [OK]/[START] key.
The soft SW data entered in procedure 1) is displayed.
* When [SW NO] key is pressed, the display returns to the ini-
tial screen.
3) When [OK]/[START] key is pressed, it is highlighted and the
setting is saved.
66-2
Purpose
Setting
Function (Purpose)
Used to enter a country code and set the
default value for the country code.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-02, the following
screen is displayed.
2) Enter the country code (8 digits) with 10 keys. .
3) When [OK]/[START] key is pressed after entering the country
code, he soft SW corresponding to the country code is initial-
ized.
Operation/Procedure (Shifting to the country page)
* When Arrow key is pressed on the initial screen, the display is
shifted to the country code list screen.
Use scroll keys to select the country select page.
<Country code list>
66-4
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected signals to the
line and the main unit speaker.
Section
FAX
Operation/Procedure
1) Select a button of a signal to be sent with Arrow keys and input
the setting values with 10 keys.
2) Determine the setting values with [OK]/[START] key.
3) Press [OK]/[START] key to send the signals.
<Signal send table>
66-7
Purpose
Data output/Check
Function (Purpose)
Used to output all image data saved in the
image memory of FAX part.
Section
FAX
Operation/Procedure
1) When [OK]/[START] key is pressed, it is highlighted and all
image data saved in the image memory are outputted.
2) After completion of printing, [EXECUTE] key returns to the nor-
mal display.
66-8
Purpose
Operation test/Check
Function (Purpose)
Used to send the selected sound mes-
sages to the line and the speaker.
Section
FAX
Operation/Procedure
1) When the machine enters Simulation 66-08, the following
screen is displayed.
2) Select an item to be set with 10 keys.
No. Country Code
1 Japan 00000000
2 U.S.A. 10110101
3 U.K. 10110100
4 China 00100110
5 India 01010011
6 Taiwan 11111110
7 Australia 00001001
8 New Zealand 01111110
9 Singapore 10011100
10 Malaysia 01101100
11 Hong Kong 01010000
12 South Africa 10011111
13 Germany 00000100
14 France 00111101
15 Spain 10100000
16 Portugal 10001011
17 Denmark 00110001
18 Norway 10000010
19 Switzerland 10100110
20 Italy 01011001
21 Belgium 00001111
22 Luxembourg 01101001
23 Netherlands 01111011
24 Finland 00111100
25 Sweden 10100101
26 Thailand 10101001
27 Czech 00101110
28 Slovakia 11111100
29 Hungary 01010001
30 Greece 01000110
31 Poland 10001010
32 Russia 10111000
33 Middle east 11111101
34 Brazil 00010110
1:NO SIGNAL
11:12000bps(v34
)
21:7200bps(V29
)
31:NO RBT
2:33600bps(V
34)
12:9600bps(v34)
22:4800bps(V27
ter)
32:DP MAKE
3:31200bps(V
34)
13:7200bps(v34)
23:2400bps(V27
ter)
33:DP BREAK
4:28800bps(v
34)
14:4800bps(v34)
24:300bps(FLA
G)
5:26400bps(v
34)
15:2400bps(v34)
25:2100Hz
(CED)
6:24000bps(v
34)
16:14400bps(v17
)
26:1100Hz
(CNG)
7:21600bps(v
34)
17:12000bps(V1
7)
27:300bps(V21)
8:19200bps(v
34)
18:9600bps(V17)
28:2100Hz
(ANSam)
9:16800bps(v
34)
19:7200bps(V17)
29:PSEUDO
RINGER
10:14400bps(
v34)
20:9600bps(V29) 30:NO MSG
No. Country Code
