MX-C250 SIMULATION 6 – 69
4.Soft switch (Detail of Sim. 66-1)
A.Soft switch list
SW
No.
Bit
No.
System set-
tings
Item SW selection and function Remarks
1 1 - 8 Country code
2 1 - 2 Not used
3 - 8 language
3 1-4 Adjustment value Minimum pause time (10PPS) set-
ting
0(525ms) -15(900ms)
X(ms) = ( N * 25 ) + 525
Two states input
5 - 8 Adjustment value Make time (10PPS) setting Setting range 26 to 41 sec-
onds (1 ms intervals)
Two states input
4 1-4 Adjustment value Minimum pause time (10PPS) set-
ting
0(525ms) - 15(900ms)
X(ms) = (N * 25) + 525
Two states input
5 - 8 Adjustment value Minimum pause time (20PPS) set-
ting
375ms 0 0 0
400ms 0 0 1
425ms 0 1 0
450ms 0 1 1
475ms 1 0 0
500ms 1 0 1
525ms 1 1 0
550ms 1 1 1
5 1-4 Adjustment value Make time (20PPS) setting Setting range 9 to 26 ms (1 ms
intervals)
Two states input
5 Not used
6 - 8 Adjustment value Setting of DTMF minimum pause
time
90ms 0 0 0
100ms 0 0 1
110ms 0 1 0
120ms 0 1 1
130ms 1 0 0
140ms 1 0 1
150ms 1 1 0
160ms 1 1 1
6 1-5 Adjustment value DTMF signal send time Setting range 6(60ms) to
31(310ms) ms
X(ms) = (N * 10)
6 - 7 Adjustment value Dial call waiting time 3.5s 0 0
4.0s 0 1
5.0s 1 0
6.0s 1 1
8 Adjustment value SDT signal detection 0: No 1: Yes
7 1 Setting No. 2 dial tone detection 0: No 1: Yes
2 Setting Dial tone detection 0: No 1: Yes
3 - 4 Adjustment value Dial tone ON detection time (dur-
ing continuous detection)
1.0s 0 0
1.5s 0 1
2.0s 1 0
5-8 Adjustment value Upper limit of dial tone ON/OFF
detection time (during intermittent
detection)
Setting range 1000ms to
4000ms (200ms intervals)
Two states input
8 1-3 Adjustment value Lower limit of dial tone ON/OFF
detection time (during intermittent
detection)
Not used 0 0 0
100ms 0 0 1
200ms 0 1 0
300ms 0 1 1
400ms 1 0 0
500ms 1 0 1
Not used 1 1 0
Not used 1 1 1
4 Not used
8 5-8 Setting External line connection number
setting 1 <First digit>
The numbers and codes which
can be registered are as fol-
lows.
0 - 9 / * (a) / # (b) / – (pause)
(c) / Not used for this digit and
after (d) /
Any is OK (f).
1
1
‘13/Aug
