MX-C250 SIMULATION 6 – 73
33 1 - 4 Setting V.34 Primary channel sending
speed
Sending Speed = 2400(bps) x
N
N : 0=2400bps
15=33600bps
Two states input
5 Setting REN EOL send out number 0 : 12 times 1 : 6 times Two states input
6 - 8 Not used
34-
35
Not used
36 1 Timer EOL detection timer 0 : 13s 1 : 25s
2 Communication/
Adjustment value
CED signal sending 0 : OFF 1 : ON
3, 4 Communication/
Adjustment value
CED signal sending time 3s 0 0
4s 0 1
5s 1 0
6s 1 1
5 Communication/
Adjustment value
CED detection time 0 : 700ms 1 : 1400ms
6 - 7 Speed/Setting Fixing of modem speed during
reception
Not fixed 0 0
V.29-9600BPS 0 1
V.27ter-4800BPS 1 0
V.17-14400BPS 1 1
8 Communication/
Setting
Echo countermeasure (CED tone
sending interval) when receiving
0 : 75ms 1 : 500ms
37 1 Protocol monitor 0 : OFF 1 : ON
2 Only at times of Protocol monitor
error
0 : OFF 1 : ON
3 Enable/Disable of 33 bit or later of
DIS (Reflected only to DIS)
0 : Enable 1 : Disable
4 CSI sending 0 : OFF 1 : ON
5 Communication/
Adjustment value
EYE Q Check 0 : Receive and EYE Q Check 1 : Only EYE Q Check
6 Communication/
Adjustment value
Time out time setting after starting
TCF signal reception
0 : 2s 1 : 4s
7 Speed/Setting TCF Check time 0 : 1.3s 1 : 1.0s
8 Adjustment value Time between DCS-TCF 0 : 150ms 1 : 75ms
38 1 - 3 Adjustment value Dial in waiting time 1000ms 0 0 0 Two states input
1200ms 0 0 1
1400ms 0 1 0
1600ms 0 1 1
1800ms 1 0 0
2000ms 1 0 1
2200ms 1 1 0
2400ms 1 1 1
4 - 7 Setting V.34 primary channel reception
speed
Sending Speed = 2400(bps) x
N
N : 0=2400bps
15=33600bps
Two states input
8 Not used
39 1, 2 Communication/
Setting
ANSam signal sending time 3s 0 0 Two states input
4s 0 1
5s 1 0
6s 1 1
3 - 5 Communication/
Setting
Reception gain changeover when
receiving
0dBm 0 0 0
1dBm 0 0 1
2dBm 0 1 0
3dBm 0 1 1
4dBm 1 0 0
5dBm 1 0 1
6dBm 1 1 0
7dBm 1 1 1
6 - 8 Not used
40-
41
Not used
SW
No.
Bit
No.
System set-
tings
Item SW selection and function Remarks
To Next Page
