MX-C250 ELECTRICAL SECTION 12 – 15
TCS_M
Detect Magenta Toner Concentra-
tion
(Analog) CN32 B11 MFPC DV Unit
TCS_Y Detect Yellow Toner Concentration (Analog) CN32 B5 MFPC DV Unit
TFD2 Detect Delivery Full Detect:Full CN21 2 MFPC Delivery Unit:TFD2
TH_M_ANI Thermal of Manual bypass (Analog) CN31 2 MFPC TH_M
TH_P Thermal of Ozone Duct (Analog) CN36 18 MFPC TH PWB
TH_UM Thermal of Fixing Unit(Main) (Analog) CN20 2 MFPC Fixing Unit:TH_UM
TH_UM_CS Thermal of Fixing Unit(Main) (Analog) CN20 1 MFPC Fixing Unit:TH_UM_CS
TH_UM2 Thermal of Fixing Unit(Sub) (Analog) CN20 6 MFPC Fixing Unit:TH_UM2
TH_US Thermal of Fixing Unit(Sub) (Analog) CN20 4 MFPC Fixing Unit:TH_US
TNC_C Cyan Toner Clutch Control Clutch On CN26 3 MFPC TNC_C
TNC_K Black Toner Clutch Control Clutch On CN26 1 MFPC TNC_K
TNC_M Magenta Toner Clutch Control Clutch On CN26 5 MFPC TNC_M
TNC_Y Yellow Toner Clutch Control Clutch On CN26 7 MFPC TNC_Y
TNFD Detect Waste Toner Full Detect:Full CN32 B3 MFPC TNFD Sensor
TSG_C
Cyan Toner Concentration Sensor
Control
(Analog) CN32 A4 MFPC DV Unit
TSG_K
Black Toner Concentration Sen-
sor Control
(Analog) CN32 A10 MFPC DV Unit
TSG_M
Magenta Toner Concentration
Sensor Control
(Analog) CN32 B13 MFPC DV Unit
TSG_Y
Yellow Toner Concentration Sen-
sor Control
(Analog) CN32 B7 MFPC DV Unit
Y_CS2
Tray2 Sensor Data(CSSELA,B,C
Code Select)
(Select Sensor
Data)
CN36 13 MFPC 2nd Cassette(Option)
Signal Name Description Connector Level Connec-
tor
number
Pin
number
PWB NOTE
