MX-C250 SIMULATION 6 – 9
The selected load performs the operation.
When [STOP] key is pressed, the operation is terminated.
Load operation check method:
The load operation is checked by the operation sound. However,
there are some loads which cannot be checked with the operation
sound.
6-3
Purpose
Operation test/check
Function (Purpose)
Used to check the operations of the primary
transfer unit and the control circuit.
Section
Process (Transfer)
Operation/Procedure
1) Press [OK]/[START] key, and the transfer unit repeats opera-
tions in the mode selected in procedure 1.
During this operation, the transfer unit status (the operation mode
position) is displayed.
6-90
Purpose
Setting
Function (Purpose)
Used to set the machine to the factory set-
tings.
Section
Scanner
Operation/Procedure
1) Press [OK]/[START] key. The scanner is moved to the position
where it can be locked.
7
7-1
Purpose
Setting
Function (Purpose)
Used to set the operating conditions of
aging.
Section
Others
Operation/Procedure
1) Select the target to be set with 10 keys...
2) Press [OK]/[START] key.
The machine is rebooted in the aging mode.
The aging operation condition set by this mode is maintained here-
after unless the power is turned off or the setting is changed.
7-6
Purpose
Setting
Function (Purpose)
Used to set the operating intermittent aging
cycle.
Section
Operation/Procedure
1) Enter the intermittent aging operation cycle (unit: sec) with 10
key.
2) Press [OK]/[START] key.
The time entered in procedure 1) is set.
* The interval time that can be set is 1 to 900 (sec).
The aging operation condition set by this mode is maintained here-
after unless the power is turned off or the setting is changed.
7-9
Purpose
Operation test/check
Function (Purpose)
Color setting in the color copy test mode
(Used to check the copy operation and the
image quality for each color).
Section
Operation/Procedure
1) Select the copy color with10 keys.
(Two or more colors can be selected.)
The key of the selected color is highlighted.
2) Press [OK]/[START] key.
Copying is performed with the selected color.
When [BACK] key is pressed, the display goes into the copy opera-
tion menu in the simulation mode.
7-12
Purpose
Operation test/check
Function (Purpose)
The document reading number of sheets
setting (for aging operation)
Section
RSPF
Operation/Procedure
1) Set document reading quantity with 10 key.
(Setting range:0 - 255)
2) Press [OK]/[START] key. The set value is saved.
The aging operation condition set by this mode is maintained here-
after unless the power is turned off or the setting is changed.
Item/Display Content
POFM Paper exit cooling fan motor
PSFM Power PWB cooling fan motor
LSUFM LSU cooling fan motor
OZFM1 Ozone fan motor 1
Mode
select key
Display
Transfer
mode
Operation
TC1 BLACK Black mode
position
The switching operations are
repeated as follows: Drum separa-
tion position - Black mode position -
Color mode position
COLOR Color mode
position
FREE Drum sepa-
ration posi-
tion
No. Item/Display Content
Setting
range
Setting
value
1 AGING Aging operation setup 0-1 0
2 INTERVAL Intermittent setup 0-1 0
3
MISFEED
DISABLE
JAM detection enable/disable
setup
0-1 0
4
FUSING DIS-
ABLE
Fusing operation enable/dis-
able setup
0-1 0
5
WARMUP
DISABLE
Warm-up skip setup 0-1 0
6
DV CHECK
DISABLE
DV unit detection enable/dis-
able setup
0-1 0
7
SHADING
DISABLE
Shading disable setup 0-1 0
8
CCD GAIN
FREE
No setting of the CCD gain
adjustment
0-1 0
No. Item/Display Content
Setting
range
Setting
value
1 K Setup/cancel of black 0-1 0
2 C Setup/cancel of cyan 0-1 0
3 M Setup/cancel of magenta 0-1 0
4 Y Setup/cancel of yellow 0-1 0
To Next Page
