70
TROUBLESHOOTING
Misfeed in the paper feed area A
1
Carefully remove the misfed paper. Turn the roller rotating knob in the direction of the
arrow to assist in removing it.
Be careful not to tear the misfed paper during removal.
2
Close the side cover.
The message " Clear paper path." will be cleared and printing will be possible.
Misfeed in the fusing area B
1
Lower the fusing unit release levers to allow easier removal.
2
Lower the part with the green label that protrudes from the fusing unit paper guide,
and open the fusing unit paper guide.
The fusing unit is hot. Do not touch the fusing
unit when removing misfed paper. Doing so may
cause a burn or injury.
When removing misfed paper, do not touch or damage the
transfer belt.
• When closing the side cover, press on around the handle.
• If the message does not clear, check again to make sure that no pieces of paper remain.
Roller rotating knob
Fusing unit
Fusing unit release levers
To Next Page
