34
TROUBLESHOOTING AND MAINTENANCE
MISFEED IN TRAY 2
1
Open the side cover.
Grasp the handle to open the
side cover.
2
Remove the misfed paper.
Be careful not to tear the misfed
paper during removal.
3
If there was no misfed paper in step 2,
pull out tray 2 and remove the misfed
paper.
Be careful not to tear the misfed
paper during removal.
4
Gently close the side cover.
The message " Clear paper
path." will be cleared and
copying will be possible.
5
Gently push tray 2 into the machine.
Push the tray in completely.
• Make sure that there is no misfed paper in the tray before pulling it out. (Page 31)
• Also use the following procedure to remove misfeeds that occur in the 250-sheet paper feed unit and the 2 x
250-sheet paper feed unit.
Note
If the message does not clear, check again
to make sure that no pieces of paper
remain.
Side cover
Note
Side cover
2 x 250-sheet paper feed unit (AR-D35)
To Next Page
