(8) USB connector (A type)
Supports USB 2.0 (Hi-Speed).
This is used to connect a USB device such as USB
memory to the machine.
For the USB cable, use a shielded cable.
(9) Keyboard*
The keyboard is integrated into the main unit.
If not using the keyboard, it can be retracted into the
bottom of the operation panel.
☞ ENTERING TEXT FROM A KEYBOARD (page 1-56)
(10) Main power switch
This is used to power on the machine.
When using the fax or Internet fax functions, keep this
switch in the "on" position.
☞ TURNING THE POWER ON AND OFF (page 1-14)
(11) Tray 1
This holds paper.
☞ TRAY SETTINGS FOR TRAY 1 TO 4 (page 1-31)
(12) Tray 2
This holds paper.
☞ TRAY SETTINGS FOR TRAY 1 TO 4 (page 1-31)
(13) Tray 3 (when a paper drawer is installed)*
This holds paper.
☞ TRAY SETTINGS FOR TRAY 1 TO 4 (page 1-31)
(14) Tray 4 (when a paper drawer is installed)*
This holds paper.
☞ TRAY SETTINGS FOR TRAY 1 TO 4 (page 1-31)
* Peripheral device.
(8) (9)
(12)(11)(10) (13) (14)
