PARTS NAME
Louvers
(Air outlet of Plasmacluster Ions)
High density Plasmacluster Ions are discharged
forward. (Do not put anything in front of the unit.)
Plasmacluster Ion Generating Unit
(Inside)
Please open the cover only when cleaning or
replacing the Plasmacluster Ion Generating Unit.
(See page E-13)
Filter(Air Intake)
* Be sure to clean the fi lter when the fi lter clean
reminder illuminates
* Do not block the air intake or do not push
anything into the unit.
Power cord
Plug
DISPLAY
FILTER CLEAN Light
(YELLOW)
UNIT REPLACEMENT Light
(red)
HIGH Light
(blue)
MED. Light
(blue)
LOW Light
(blue)
OPERATION Button
UNIT RESET Button
FILTER RESET Button
AUTO RESTART Switch
FIX THE OPERATION COVER BY SCREW
If necessary, operation cover can be fi xed by accessory screw.
washer
screw
rubber cover
After cleaning the fi lter, plug the power cord and
press the FILTER RESET button for 3 seconds.
Use this button when replacing
Plasmacluster Ion Generating Unit.
Don't press it for any other purposes.
