SCREEN menu
Function
Command Direction
Parameter Reply Control/Response contents *
AUTO ASNC W 1 When the input mode is D-SUB[RGB].
-
CLOCK CLCK WR 0-1200 0-1200 When the input mode is D-SUB[RGB].
Varies depending on the signal.
PHASE PHSE WR 0-63 0-63 When the input mode is D-SUB[RGB].
POSITIONING POSITION OF THE
LONGEST DIRECTION
HPOS WR 0-100 0-100 0-800 on D-SUB[RGB].
Varies depending on the signal.
POSITION OF
THE SHORTEST
DIRECTION
VPOS WR 0-100 0-100 0-200 on D-SUB[RGB].
Varies depending on the signal.
SIZE SIZE OF THE
LONGEST DIRECTION
HSIZ WR 0-100 0-100
SIZE OF THE
SHORTEST
DIRECTION
VSIZ WR 0-100 0-100
RESOLUTION
SETTING
LONGEST DIRECTION
RESOLUTION
HRES WR 300-1920 300-1920 When the input mode is D-SUB[RGB].
Only even numbers are valid for parameters.
Varies depending on the signal.
SHORTEST
DIRECTION
RESOLUTION
VRES WR 200-1200 200-1200
INPUT SIGNAL (D-SUB[RGB]) PXSL WR 1 1 768) 1360 x 768
2 2 768) 1280 x 768
3 3 768) 1024 x 768
5 5 480) 848 x 480
6 6 480) 640 x 480
7 7 1050) 1680 x 1050
8 8 1050) 1400 x 1050
9 9 768) AUTO
10 10 480) AUTO
Check the resolution
(other than D-SUB[COMPONENT])
PXCK R - Returns current resolution in the form of hhh, vvv.
Check the resolution (HDMI1, HDMI2,
D-SUB[COMPONENT], OPTION (When you have
used the expansion slot to expand the functions.))
RESO R - 480i, 480p, 1080i, 720p, 1080p, VGA , etc.
ZOOM2 SPECIAL SETTING
(D-SUB[RGB])
Z2SP WR 0-1 0-1 0: OFF, 1: ON
○
RESET ARST W 1
-
