45
E
Function
Command Direction
Parameter Reply Control/Response contents *
PIP MODES MWIN WR 0-3 0-3 0: OFF, 1: PIP, 2: PbyP, 3: PbyP2
○
PIP SIZE MPSZ WR 1-64 1-64
PIP POS THE LONGEST
DIRECTION
MHPS W 0-100
R 0-100
THE SHORTEST
DIRECTION
MVPS W 0-100
R 0-100
PIP POS LD+SD BATCH MPOS W 0-100,0-100 Specify the position in MPOSxxxyyy format.
(xxx: Longer side, yyy: Shorter side position)
R 0-100,0-100 Returns a response in (xxx,yyy) format.
(xxx: Longer side, yyy: Shorter side position)
PIP BLEND MWBL WR 0-7 0-7
PIP SOURCE MWIP WR 1 1 DVI-D
2 2 D-SUB[RGB]
3 3 D-SUB[COMPONENT]
10 10 HDMI1
13 13 HDMI2
14 14 DisplayPort
21 21 OPTION (valid when you have used the expansion slot to expand the functions)
SOUND CHANGE MWAD WR 1-2 1-2 1: MAIN, 2: SUB
MAIN POS (Main screen) MWPP WR 0-1 0-1 0: POS1, 1: POS2
PbyP2 POS (Sub screen) MW2P WR 0-2 0-2 0: POS1, 1: POS2, 2: POS3
OTHERS menu
Function
Command Direction
Parameter Reply Control/Response contents *
SCREEN MOTION PATTERN SCSV WR 0-4 0-4 0: OFF, 1-4: PATTERN1-4
○
MOTION TIME1 MTIM WR 0-20 0-20
MOTION TIME2
(PATTERN1)
MINT WR 10-990 10-990 Per 10 seconds
MOTION TIME2
(PATTERN2-4)
MINT WR 5-20 5-20 Per second
POWER MANAGEMENT PMNG WR 0-1 0-1 0: OFF, 1: ON
CONNECT AUTO INPUT SELECT AICO WR 0-1 0-1 0: OFF, 1: ON
The input via the expansion slot is ignored.
NO SIGNAL AUTO INPUT SEL. AINO WR 0-1 0-1 0: OFF, 1: ON
AUTO INPUT
SELECT PRIORITY
DisplayPort APDP WR 0-10 0-10 0: Not selected by auto input selection, 1-10: Priority
“ERR” when OFF is selected for NO SIGNAL AUTO INPUT SEL..
APOP will result in an error ("ERR") when an optional part that is not a target for
this function is connected.
All input terminals cannot be set to 0 simultaneously.
HDMI1 APH1
HDMI2 APH2
DVI-D APDV
D-SUB APD1
OPTION APOP
LOGO SCREEN BTSC WR 0-1 0-1 0: OFF, 1: ON
SCAN MODE
(HDMI1, HDMI2, D-SUB[COMPONENT],
OPTION (When you have used the expansion
slot to expand the functions.))
SCAN WR 0-2 0-2 0: MODE1, 1: MODE2, 2: MODE3
Initialization/Functional Restriction Setting (FUNCTION) menu
Function
Command Direction
Parameter Reply Control/Response contents *
ALL RESET RSET W 0-1 0: ALL RESET 1, 1: ALL RESET 2 -
ADJUSTMENT LOCK ALCK WR 0-2 0-2 0: OFF, 1:ON1, 2:ON2
●
ADJUSTMENT LOCK TARGET ALTG WR 0-2 0-2 0: REMOTE CONTROL, 1: MONITOR BUTTONS, 2: BOTH
○
OSD DISPLAY LOSD WR 0-2 0-2 0: ON1, 1: OFF, 2: ON2
LED OFLD WR 0-1 0-1 0: ON, 1: OFF
TEMPERATURE ALERT TALT WR 0-2 0-2 0: OFF, 1: OSD & LED, 2: LED
STATUS ALERT SALT WR 0-2 0-2 0: OFF, 1: OSD & LED, 2: LED
POWER BUTTON PBTN WR 0-1 0-1 0: MONITOR, 1: EXT. CONTROLLER
EXTERNAL CONTROLLER INPUT PCIP WR 0-4 0-4 0: D-SUB, 1: DisplayPort, 2: HDMI1, 3: HDMI2, 4: DVI-D
(“ERR” when MONITOR is selected for POWER BUTTON.)
SIGNAL RESPONSE LEVEL HDUC WR 1-200 1-200
Controlling the Monitor with a PC (RS-232C)
